12 How to assemble your monitor hardware
3. Connect the audio cable.
Connect the audio cable between the socket on the
rear of the monitor (Line In) and your computer audio
outlet.
You may connect headphones to the headphone jack
found next to the Line In jack of the monitor.
4. Connect the power cable to the monitor.
Connect the power cord to the power adapter. Plug
one end of the power cord into the socket labelled
on the rear of the monitor. Do not connect the other
end to a power outlet just yet.
5. Organize the cables.
1
2
