Motorola MBP853 [15/364] Using the baby monitor

Using the Baby Monitor 15

ENGLISH

3. Using the Baby Monitor

3.1 Setting up

• Place the Baby Unit in a convenient location (e.g. on a table) and point the

camera lens towards the area you want to monitor.

• Adjust the angle of the Baby Unit's head by rotating the camera up, down, left

and right until you are satisfied with the image in the Parent Unit.

NOTE

Do not place the Baby Unit within the baby's reach! If there is interference with

the picture or sound, try moving the units to different locations, and ensure they

are not close to other electrical equipment.

3.2 Pan and Tilt

The camera can be remotely controlled from the Parent Unit.

1. Press the UP button or

DOWN button to tilt up or down.

2. Press the LEFT button or RIGHT button to pan left or right.

3.3 Night Vision Mode

The Baby Unit has 8 high-intensity infrared LEDs for picking up clear images in the

dark. When the built-in photo sensor on the top of the unit detects a low level of

ambient light, the LEDs will automatically activate and the screen on the Parent Unit

will display in black and white. The icon will be displayed at the top of the screen.

3.4 Talk Mode

Press and hold the

TALK button on the Parent Unit to talk to your baby through the

Baby Unit’s loudspeaker. The

icon will be displayed at the top of the LCD screen.

3.5 Video ON/OFF

Press V VIDEO ON/OFF key to turn the LCD display on or off, whilst still

leaving the audio monitor on.

3.6 Temperature Display (HH °C / °F or LL °C / °F)

The temperature reading from the temperature sensor at the back of the Baby

Unit will be displayed at the top of the LCD screen. The readings will turn RED if

the temperature goes above 29°C / 84°F or below 14°C / 57°F. The reading will

change to HH °C / °F if the temperature goes above 36°C / 97°F. The reading

will change to LL °C / °F if the temperature goes below 1°C / 34°F.
