GMC SAVANA CARGO (2014) [146/404] 44 instruments and controls
![GMC SAVANA CARGO (2014) [146/404] 44 instruments and controls](/views2/1986514/page146/bg92.png)
Black plate (44,1)
GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-6014682) -
2014 - crc - 4/9/13
5-44 Instruments and Controls
FACTORY SETTINGS
This feature allows you to set all of
the customization features back to
their factory default settings.
Press
U until FACTORY SETTINGS
appears on the DIC display. Press
V once to access the settings for
this feature. Then press
U to scroll
through the following settings:
RESTORE ALL (default): The
customization features will be set to
their factory default settings.
DO NOT RESTORE: The
customization features will not be
set to their factory default settings.
To select a setting, press
V while
the desired setting is displayed on
the DIC.
EXIT FEATURE SETTINGS
This feature allows you to exit the
feature settings menu.
Press
U until FEATURE SETTINGS
PRESS
V TO EXIT appears in the
DIC display. Press
V once to exit
the menu.
If you do not exit, pressing
U will
return you to the beginning of the
feature settings menu.
Exiting the Feature
Settings Menu
The feature settings menu will be
exited when any of the following
occurs:
.
The vehicle is no longer in
ON/RUN.
.
The 3 or T DIC buttons are
pressed.
.
The end of the feature settings
menu is reached and exited.
.
A 40 second time period has
elapsed with no selection made.
