![GMC SAVANA CARGO (2014) [22/404] Bluetooth](/img/pdf.png)
GMC SAVANA CARGO (2014) [22/404] Bluetooth
![GMC SAVANA CARGO (2014) [22/404] Bluetooth](/views2/1986514/page22/bg16.png)
Black plate (16,1)
GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-6014682) -
2014 - crc - 4/9/13
1-16 In Brief
Bluetooth
®
If equipped with a Bluetooth
system, it allows users with a
Bluetooth-enabled cell phone to
make and receive hands-free calls
using the vehicle’s audio system
and controls.
The Bluetooth-enabled cell phone
must be paired with the Bluetooth
system before it can be used in the
vehicle. Not all phones will support
all functions. For more information,
see www.gm.com/bluetooth and
Bluetooth on page 7-21.
Steering Wheel Controls
For vehicles with audio steering
wheel controls, some audio controls
can be adjusted at the steering
wheel.
w : Press to go to the next favorite
radio station, track on a CD,
or folder on an iPod
®
or USB
device.
c / x : Press to go to the
previous favorite radio station, track
on a CD, or folder on an iPod
®
or
USB device. Also press to reject an
incoming call, or end a current call.
b / g : Press to silence the vehicle
speakers only. Press again to turn
the sound on. Press and hold longer
than two seconds to interact with
OnStar
®
or Bluetooth systems,
if equipped.
+
e : Press to increase volume.
−
e : Press to decrease volume.
SRCE: Press to switch between
the radio and CD, and for equipped
vehicles, the front auxiliary.
¨ : Press to seek the next radio
station, the next track while sourced
to the CD, or to select tracks and
folders on an iPod
®
or USB device.
For more information, see Steering
Wheel Controls on page 5-2.
