GMC SAVANA CARGO (2014) [172/404] 18 infotainment system
![GMC SAVANA CARGO (2014) [172/404] 18 infotainment system](/views2/1986514/page172/bgac.png)
Black plate (18,1)
GMC Savana Owner Manual (GMNA-Localizing-U.S./Canada-6014682) -
2014 - crc - 4/9/13
7-18 Infotainment System
USB Support
If equipped, the USB port is on the
instrument panel and uses the
USB 2.0 standard.
USB-Supported Devices
.
USB flash drive
.
Portable USB hard drive
.
Fifth generation or later iPod
.
iPod nano
®
.
iPod touch
®
.
iPod classic
®
Not all iPods and USB drives are
compatible with the USB port.
Make sure the iPod has the latest
firmware from Apple
®
for proper
operation. iPod firmware can be
updated using the latest iTunes
®
application. See www.apple.com/
itunes.
For help with identifying the iPod, go
to www.apple.com/support.
Radios that have a USB port can
play .mp3 and .wma files that are
stored on a USB storage device as
well as AAC files that are stored on
an iPod.
USB-Supported File and Folder
Structure
The radio supports:
.
Up to 700 folders.
.
Up to eight folders in depth.
.
Up to 65,535 files.
.
Folder and file names up to
64 bytes.
.
Files with an .mp3 or .wma file
extension.
.
AAC files stored on an iPod.
.
FAT16.
.
FAT32.
Connecting a USB Storage
Device or iPod
The USB port can be used to
control an iPod or a USB storage
device.
To connect a USB storage device,
connect the device to the USB port
on the instrument panel.
To connect an iPod, connect one
end of the USB cable that came
with the iPod to the iPod’s dock
connector and connect the other
end to the USB port on the
instrument panel. If the vehicle is on
and the USB connection works, “OK
to disconnect” and a GM logo may
appear on the iPod, and iPod
appears on the radio display. The
iPod music appears on the radio
display and begins playing.
