For additional information, see “TIRE PRESSURE
MONITORING SYSTEM (TPMS)” in the “5. Start-
ing and driving” section and “TIRE PRESSURE
MONITORING SYSTEM (TPMS)” in the “6. In case
of emergency” section.
TPMS malfunction :
If the TPMS is not functioning properly, the low
tire pressure warning light will flash for approxi-
mately 1 minute when the ignition switch is
pushed ON. The light will remain on after the 1
minute. Have the system checked by an INFINITI
dealer.
For additional information, see “TIRE PRESSURE
MONITORING SYSTEM (TPMS)” in the “5. Start-
ing and driving” section.
WARNING
● If the light does not illuminate with the igni-
tion switch pushed ON, have the vehicle
checked by an INFINITI dealer as soon as
possible.
● If the light illuminates while driving, avoid
sudden steering maneuvers or abrupt brak-
ing, reducevehicle speed, pull off the road to
a safe location and stop the vehicle as soon
as possible.Driving with under-inflated tires
may permanently damage the tires and in-
crease the likelihood of tire failure. Serious
vehicle damage could occur and may lead to
an accident and could result in serious per-
sonal injury. Check the tire pressure for all
four tires. Adjust the tire pressure to the rec-
ommended COLD tire pressure shown on the
Tire and Loading Information label to turn
the lowtire pressure warning light OFF. If the
light still illuminates while driving after ad-
justing the tire pressure, a tire may be flat. If
you have a flat tire, replace it with a spare
tire as soon as possible.
● When a spare tire is mounted or a wheel is
replaced, the TPMS will not function and the
low tire pressure warning light will flash for
approximately 1 minute. The light will re-
main on after 1 minute. Contact your INFINITI
dealer as soon as possible for tire replace-
ment and/or system resetting.
● Replacing tires with those not originally
specified by INFINITI could affect the proper
operation of the TPMS.
CAUTION
● The TPMS is not a substitute for the regular
tire pressure check. Be sure to check the tire
pressure regularly.
● If thevehicle is beingdriven at speedsofless
than 16 MPH (25 km/h), the TPMS may not
operate correctly.
● Be sure to install the specifiedsize of tiresto
the four wheels correctly.
Low washer fluid warning
light
This light comes on when the washer tank fluid
is at a low level. Add washer fluid as necessary.
(See “WINDOW WASHER FLUID” in the “8. Main-
tenance and do-it-yourself” section.)
Master warning light
When the ignition switch is in the ON position,
the master warning light illuminates if any of
the following are displayed on the dot matrix
liquid crystal display:
● No key warning
● Low fuel warning
● Low washer fluid warning
Instruments and controls 2-15
w —
—
11/14/07—debbie
X
Содержание
- 11 14 07 debbi 1
- Foreword 1
- Infiniti ex35 owner s manual 1
- Read first then drive safely 1
- 11 14 07 debbi 2
- Caution 2
- Important information about this manual 2
- Modification of your vehicle 2
- Warning 2
- When reading the manual 2
- 11 14 07 debbi 3
- California perchlorate advisory 3
- California proposition 65 warning 3
- Warning 3
- 11 14 07 debbi 4
- Infiniti customer care program 4
- Om8e 0j50u0 5
- Table of contents 5
- 11 14 07 debbi 7
- Illustrated table of contents 7
- 11 15 07 tbrook 8
- Illustrated table of contents 8
- Seats seat belts and supplemental restraint system srs 8
- 11 14 07 debbi 9
- Exterior front 9
- Illustrated table of contents 9
- 11 14 07 debbi 10
- Exterior rear 10
- Illustrated table of contents 10
- 11 14 07 debbi 11
- Illustrated table of contents 11
- Passenger compartment 11
- 11 14 07 debbi 12
- Cockpit 12
- Illustrated table of contents 12
- 11 14 07 debbi 13
- Illustrated table of contents 13
- 11 14 07 debbi 14
- Illustrated table of contents 14
- Instrument panel 14
- 11 14 07 debbi 15
- Illustrated table of contents 15
- Meters and gauges 15
- 11 14 07 debbi 16
- Engine compartment 16
- Vq35hr engine 16
- 11 14 07 debbi 17
- Safety seats seat belts and supplemental restraint system 17
- 11 14 07 debbi 18
- Front seats front power seat adjustment 18
- 11 14 07 debbi 19
- Safety seats seat belts and supplemental restraint system 19
- Warning 19
- 11 15 07 tbrook 20
- Rear seats 20
- 11 14 07 debbi 21
- Power folding 21
- 11 14 07 debbi 22
- Adjustment 22
- Head restraint 22
- Manual folding 22
- 11 14 07 debbi 23
- Front seat active head restraints 23
- Safety seats seat belts and supplemental restraint system 23
- Warning 23
- 11 14 07 debbi 24
- Armrest if so equipped 24
- Precautions on seat belt usage 24
- Rear armrest 24
- Seat belts 24
- 11 14 07 debbi 25
- Safety seats seat belts and supplemental restraint system 25
- Warning 25
- 11 14 07 debbi 26
- Safety seats seat belts and supplemental restraint system 26
- 11 14 07 debbi 27
- Child safety 27
- Infants 27
- Larger children 27
- Safety seats seat belts and supplemental restraint system 27
- Small children 27
- Warning 27
- 11 14 07 debbi 28
- Injured persons 28
- Pregnant women 28
- Safety seats seat belts and supplemental restraint system 28
- Three point type seat belt 28
- Warning 28
- 11 14 07 debbi 29
- Fastening the seat belts 29
- Safety seats seat belts and supplemental restraint system 29
- Warning 29
- 11 14 07 debbi 30
- Checking seat belt operation 30
- Shoulder belt height adjustment for front seats 30
- Unfastening the seat belts 30
- 11 14 07 debbi 31
- Rear seat belt comfort guide 31
- 11 14 07 debbi 32
- Rear center seat belt 32
- Safety seats seat belts and supplemental restraint system 32
- Seat belt extenders 32
- Seat belt maintenance 32
- Warning 32
- 11 14 07 debbi 33
- Child restraints 33
- Precautions on child restraints 33
- 11 14 07 debbi 34
- Caution 34
- Safety seats seat belts and supplemental restraint system 34
- 11 14 07 debbi 35
- Lower anchors and tethers for children system latch 35
- Safety seats seat belts and supplemental restraint system 35
- 11 14 07 debbi 36
- Installing child restraint latch anchor attachments 36
- Latch lower anchor point locations 36
- Safety seats seat belts and supplemental restraint system 36
- Warning 36
- 11 14 07 debbi 37
- Installing top tether strap 37
- Safety seats seat belts and supplemental restraint system 37
- Top tether anchor point locations 37
- Top tether strap child restraint 37
- Warning 37
- 11 14 07 debbi 38
- Child restraint installation using latch 38
- Front facing 38
- Safety seats seat belts and supplemental restraint system 38
- Warning 38
- 11 14 07 debbi 39
- Safety seats seat belts and supplemental restraint system 39
- 11 14 07 debbi 40
- Check to make sure the child restraint is properly secured prior to each use if the child restraint is loose repeat steps 3 through 6 40
- If the child restraint is equipped with a top tether strap route the top tether strap and secure the tether strap to the tether anchor point see top tether strap child restraint earlier in this section 40
- Safety seats seat belts and supplemental restraint system 40
- 11 14 07 debbi 41
- Rear facing 41
- Safety seats seat belts and supplemental restraint system 41
- 11 14 07 debbi 42
- Child restraint installation using the seat belts 42
- Safety seats seat belts and supplemental restraint system 42
- Warning 42
- 11 14 07 debbi 43
- Front facing 43
- Safety seats seat belts and supplemental restraint system 43
- 11 14 07 debbi 44
- Safety seats seat belts and supplemental restraint system 44
- 11 14 07 debbi 45
- Safety seats seat belts and supplemental restraint system 45
- 11 14 07 debbi 46
- Rear facing 46
- Safety seats seat belts and supplemental restraint system 46
- 11 14 07 debbi 47
- Safety seats seat belts and supplemental restraint system 47
- 11 14 07 debbi 48
- Check that the retractor is in the alr mode by trying to pull more seat belt out of the retractor if you cannot pull any more seat belt webbing out of the retrac tor the retractor is in the alr mode 8 check to make sure that the child re straint is properly secured prior to each use if the belt is not locked repeat steps 3 through 6 48
- Remove any additional slack from the child restraint press downward and rear ward firmly in the center of the child restraint with your hand to compress the vehicle seat cushion and seatback while pulling up on the seat belt 48
- Safety seats seat belts and supplemental restraint system 48
- 11 14 07 debbi 49
- Booster seats 49
- Precautions on booster seats 49
- 11 14 07 debbi 50
- Safety seats seat belts and supplemental restraint system 50
- 11 14 07 debbi 51
- Booster seat installation 51
- Caution 51
- Safety seats seat belts and supplemental restraint system 51
- Warning 51
- 11 14 07 debbi 52
- Safety seats seat belts and supplemental restraint system 52
- 11 14 07 debbi 53
- Precautions on supplemental restraint system 53
- Supplemental restraint system 53
- 11 14 07 debbi 54
- Safety seats seat belts and supplemental restraint system 54
- Warning 54
- 11 14 07 debbi 55
- Safety seats seat belts and supplemental restraint system 55
- 11 14 07 debbi 56
- Safety seats seat belts and supplemental restraint system 56
- Warning 56
- 11 14 07 debbi 57
- Safety seats seat belts and supplemental restraint system 57
- Warning 57
- 11 14 07 debbi 58
- Infiniti advanced air bag system front seats 58
- Safety seats seat belts and supplemental restraint system 58
- 11 14 07 debbi 59
- Safety seats seat belts and supplemental restraint system 59
- 11 14 07 debbi 60
- Front passenger air bag and status light 60
- Safety seats seat belts and supplemental restraint system 60
- Warning 60
- 11 14 07 debbi 61
- Other supplemental front impact air bag precautions 61
- Safety seats seat belts and supplemental restraint system 61
- Warning 61
- 11 14 07 debbi 62
- Safety seats seat belts and supplemental restraint system 62
- 11 14 07 debbi 63
- Front seat mounted side impact supplemental air bag and roof mounted curtain side impact supplemental air bag systems 63
- Safety seats seat belts and supplemental restraint system 63
- 11 14 07 debbi 64
- Safety seats seat belts and supplemental restraint system 64
- Seat belts with pretensioners front seats 64
- Warning 64
- 11 15 07 tbrook 65
- Srs air bag 65
- Srs side impact air bag 65
- Supplemental air bag warning labels 65
- 11 14 07 debbi 66
- Repair and replacement procedure 66
- Safety seats seat belts and supplemental restraint system 66
- Supplemental air bag warning light 66
- Warning 66
- 11 14 07 debbi 67
- Safety seats seat belts and supplemental restraint system 67
- 11 14 07 debbi 68
- Instruments and controls 68
- 11 14 07 debbi 69
- 11 14 07 debbi 70
- Cockpit 70
- Instruments and controls 70
- 11 14 07 debbi 71
- Instruments and controls 71
- 11 14 07 debbi 72
- Instrument panel 72
- Instruments and controls 72
- 11 14 07 debbi 73
- Instruments and controls 73
- Meters and gauges 73
- 11 14 07 debbi 74
- Odometer twin trip odometer 74
- Speedometer 74
- Speedometer and odometer 74
- 11 14 07 debbi 75
- Engine coolant temperature gauge 75
- Tachometer 75
- 11 16 07 tbrook 76
- Fuel gauge 76
- 11 14 07 debbi 77
- Instruments and controls 77
- 11 14 07 debbi 78
- Caution 78
- Instruments and controls 78
- Zone variation change procedure 78
- 11 14 07 debbi 79
- Checking bulbs 79
- Warning indicator lights and audible reminders 79
- 11 14 07 debbi 80
- All wheel drive awd warning light awd models 80
- Anti lock braking system abs warning light 80
- Automatic transmission check warning light 80
- Brake warning light 80
- Caution 80
- Instruments and controls 80
- Warning lights 80
- 11 14 07 debbi 81
- Caution 81
- Charge warning light 81
- Engine oil pressure warning light 81
- Instruments and controls 81
- Warning 81
- 11 14 07 debbi 82
- Instruments and controls 82
- Intelligent cruise control icc system warning light orange if so equipped 82
- Intelligent key warning light 82
- Lane departure warning light orange if so equipped 82
- Low tire pressure warning light 82
- 11 14 07 debbi 83
- Caution 83
- Instruments and controls 83
- Low washer fluid warning light 83
- Master warning light 83
- Warning 83
- 11 14 07 debbi 84
- Adaptive front lighting system afs indicator light if so equipped 84
- Indicator lights 84
- Instruments and controls 84
- Preview function warning light orange if so equipped 84
- Seat belt warning light and chime 84
- Supplemental air bag warning light 84
- Warning 84
- 11 14 07 debbi 85
- Automatic transmission position indicator light 85
- Front passenger air bag status light 85
- High beam indicator light blue 85
- Instruments and controls 85
- Lane departure prevention ldp on indicator light green if so equipped 85
- Malfunction indicator light mil 85
- 11 27 07 patti 86
- Caution 86
- Instruments and controls 86
- Security indicator light 86
- Slip indicator light 86
- Turn signal hazard indicator lights 86
- Vehicle dynamic control vdc off indicator light 86
- 11 14 07 debbi 87
- Audible reminders key reminder chime 87
- Brake pad wear warning 87
- Lane departure warning chime if so equipped 87
- Light reminder chime 87
- Parking brake reminder chime 87
- 11 14 07 debbi 89
- Indicators for operation 1 engine start operation indicator 89
- Instruments and controls 89
- Intelligent key insertion indicator 89
- Intelligent key removal indicator 89
- No key warning 89
- Push warning 89
- Shift p warning 89
- Steering lock release malfunction indicator 89
- 11 14 07 debbi 90
- Cruise indicator 90
- Door lift gate open warning ignition switch is in the on position 90
- Instruments and controls 90
- Intelligent cruise control icc system main switch indicator if so equipped 90
- Intelligent key battery discharge indicator 90
- Low fuel warning 90
- Low outside temperature warning 90
- Low washer fluid warning 90
- Parking brake release warning 90
- Time to rest indicator 90
- 11 14 07 debbi 91
- Indicators for maintenance 1 engine oil replacement indicator 91
- Instruments and controls 91
- Oil filter replacement indicator 91
- Other indicator 91
- Tire replacement indicator 91
- 11 14 07 debbi 92
- Trip computer 92
- 11 14 07 debbi 93
- Average fuel consumption mpg or l liter 100 km and speed mph or km h 93
- Current fuel consumption 93
- Distance to empty dte mls or km 93
- Elapsed time and trip odometer mls or km 93
- 11 14 07 debbi 94
- Outside air temperature icy c or f 94
- Setting 94
- 11 14 07 debbi 95
- Vehicle security system 95
- Warning check 95
- 11 14 07 debbi 96
- How to arm the vehicle security system 96
- How to stop an activated alarm 96
- Infiniti vehicle immobilizer system 96
- Instruments and controls 96
- Vehicle security system activation 96
- 11 14 07 debbi 97
- Instruments and controls 97
- Security indicator light 97
- 11 14 07 debbi 98
- Windshield wiper and washer operation 98
- 11 14 07 debbi 99
- Rear window wiper and washer operation 99
- 11 14 07 debbi 100
- Headlight and turn signal switch 100
- Xenon headlights if so equipped 100
- 11 14 07 debbi 101
- Autolight system if so equipped 101
- Headlight switch 101
- Lighting 101
- 11 14 07 debbi 102
- Battery saver system 102
- Headlight beam select 102
- 11 14 07 debbi 103
- Adaptive front lighting system afs if so equipped 103
- Daytime running light system canada only 103
- Instruments and controls 103
- Warning 103
- 11 14 07 debbi 104
- Instrument brightness control 104
- 11 14 07 debbi 105
- Fog light switch 105
- Lane change signal 105
- Turn signal 105
- Turn signal switch 105
- 11 14 07 debbi 106
- Caution 106
- Horn heated seats if so equipped 106
- Instruments and controls 106
- Warning 106
- 11 14 07 debbi 107
- Lane departure warning ldw switch if so equipped 107
- 11 14 07 debbi 108
- Snow mode switch if so equipped vehicle dynamic control vdc off switch 108
- 11 14 07 debbi 109
- Adjusting the time 109
- 11 14 07 debbi 110
- Cup holders 110
- Power outlet storage 110
- 11 14 07 debbi 111
- Instruments and controls 111
- 11 14 07 debbi 112
- Console box 112
- Glove box 112
- Sunglasses holder 112
- 11 14 07 debbi 113
- Card holder 113
- Coat hooks 113
- Seat mounted jacket hanger if so equipped 113
- 11 14 07 debbi 114
- Cargo cover if so equipped 114
- 11 14 07 debbi 115
- Caution 115
- Instruments and controls 115
- Roof rack if so equipped 115
- Warning 115
- 11 14 07 debbi 116
- Locking passengers windows 116
- Main power window switch driver s side 116
- Power windows 116
- 11 14 07 debbi 117
- Auto reverse function 117
- Automatic operation for front door windows 117
- Instruments and controls 117
- Passenger side power window switch 117
- Warning 117
- 11 14 07 debbi 118
- Automatic moonroof 118
- If the windows do not close automatically 118
- Sliding the moonroof 118
- Sunshade 118
- Tilting the moonroof 118
- 11 14 07 debbi 119
- Auto reverse function 119
- If the moonroof does not operate 119
- 11 14 07 debbi 120
- Map lights 120
- Personal lights 120
- 11 14 07 debbi 121
- Door position 121
- Interior light control switch 121
- Off position 121
- On position 121
- 11 14 07 debbi 122
- Vanity mirror lights cargo light if so equipped homelink universal transceiver if so equipped 122
- 11 14 07 debbi 123
- Programming homelink 123
- 11 14 07 debbi 124
- Instruments and controls 124
- 11 14 07 debbi 125
- Clearing the programmed information 125
- Instruments and controls 125
- Operating the homelink universal transceiver 125
- Programming homelink for canadian customers 125
- Programming trouble diagnosis 125
- Reprogramming a single homelink button 125
- 11 14 07 debbi 126
- If your vehicle is stolen 126
- Instruments and controls 126
- 11 14 07 debbi 127
- Pre driving checks and adjustments 127
- 11 14 07 debbi 128
- Intelligent key 128
- 11 14 07 debbi 129
- Caution 129
- Mechanical key 129
- Pre driving checks and adjustments 129
- Valet hand off 129
- 11 14 07 debbi 130
- Locking with mechanical key 130
- Opening and closing windows with the mechanical key 130
- 11 14 07 debbi 131
- Locking with inside lock knob 131
- Locking with power door lock switch 131
- Lockout protection 131
- Vehicle speed sensing door lock mechanism 131
- 11 14 07 debbi 132
- Automatic door unlock mechanism 132
- Child safety rear door lock 132
- 11 14 07 debbi 133
- Caution 133
- Pre driving checks and adjustments 133
- 11 14 07 debbi 134
- Door locks unlocks precaution 134
- Intelligent key operating range 134
- 11 14 07 debbi 135
- Intelligent key operation 135
- Pre driving checks and adjustments 135
- 11 14 07 debbi 136
- Battery saver system 136
- Locking doors and fuel filler door 136
- Unlocking doors and fuel filler door 136
- Warning signals 136
- 11 14 07 debbi 137
- Pre driving checks and adjustments 137
- Troubleshooting guide 137
- 11 14 07 debbi 138
- How to use remote keyless entry system 138
- Locking doors and fuel filler door 138
- Unlocking doors and fuel filler door 138
- 11 14 07 debbi 139
- Opening windows 139
- Setting hazard indicator and horn mode 139
- Using panic alarm 139
- 11 14 07 debbi 140
- Pre driving checks and adjustments 140
- 11 14 07 debbi 141
- Hood lift gate 141
- 11 14 07 debbi 142
- Lift gate release lever 142
- Opening the fuel filler door 142
- 11 14 07 debbi 143
- Caution 143
- Fuel filler cap 143
- Pre driving checks and adjustments 143
- Warning 143
- 11 14 07 debbi 144
- Manual operation if so equipped 144
- Tilt or telescopic operation 144
- 11 14 07 debbi 145
- Electric operation if so equipped 145
- Tilt or telescopic operation 145
- 11 14 07 debbi 146
- Inside mirror 146
- Manual anti glare type 146
- 11 14 07 debbi 147
- Automatic anti glare type 147
- Outside mirrors 147
- 11 14 07 debbi 148
- Adjusting outside mirrors 148
- Defrosting outside mirrors if so equipped 148
- Foldable outside mirrors 148
- Reverse tilt down feature if so equipped 148
- 11 14 07 debbi 149
- Automatic drive positioner if so equipped 149
- Cancel or activate entry exit function 149
- Entry exit function 149
- Vanity mirror 149
- 11 14 07 debbi 150
- Cancel or activate seat synchronization function 150
- Initialize entry exit function 150
- Pre driving checks and adjustments 150
- Seat synchronization function 150
- 11 14 07 debbi 151
- Confirming memory storage 151
- Linking intelligent key to a stored memory position 151
- Memory storage 151
- Pre driving checks and adjustments 151
- Selecting the memorized position 151
- 11 14 07 debbi 152
- Pre driving checks and adjustments 152
- System operation 152
- 11 14 07 debbi 153
- Monitor climate audio phone and voice recognition systems 153
- 11 14 07 debbi 154
- 11 14 07 debbi 155
- 11 14 07 debbi 156
- Monitor climate audio phone and voice recognition systems 156
- Safety note center multi function control panel 156
- Warning 156
- 11 14 07 debbi 157
- Monitor climate audio phone and voice recognition systems 157
- 11 14 07 debbi 158
- Monitor climate audio phone and voice recognition systems 158
- 11 14 07 debbi 159
- How to use infiniti controller 159
- How to use touch screen models with navigation system 159
- Touch screen operation 159
- 11 14 07 debbi 160
- Touch screen maintenance 160
- 11 14 07 debbi 161
- Available items 161
- Monitor climate audio phone and voice recognition systems 161
- Start menu 161
- Start up screen models with navigation system 161
- 11 14 07 debbi 162
- How to select menus on the screen 162
- Monitor climate audio phone and voice recognition systems 162
- 11 14 07 debbi 163
- How to use brightness control and display on off button 163
- How to use info button 163
- How to use status button 163
- Vehicle information and settings 163
- 11 14 07 debbi 164
- Fuel economy information 164
- Monitor climate audio phone and voice recognition systems 164
- Vehicle information display 164
- 11 14 07 debbi 165
- Maintenance information 165
- Monitor climate audio phone and voice recognition systems 165
- 11 14 07 debbi 166
- Monitor climate audio phone and voice recognition systems 166
- Voice recognition information models with navigation system 166
- 11 14 07 debbi 167
- How to use setting button 167
- Monitor climate audio phone and voice recognition systems 167
- 11 14 07 debbi 168
- Audio settings 168
- Monitor climate audio phone and voice recognition systems 168
- 11 14 07 debbi 169
- Display settings 169
- Monitor climate audio phone and voice recognition systems 169
- Navigation settings if so equipped 169
- 11 14 07 debbi 170
- Beeps settings models without navigation system 170
- Clock settings if so equipped 170
- Monitor climate audio phone and voice recognition systems 170
- Phone settings if so equipped 170
- Volume and beeps settings models with navigation system 170
- 11 14 07 debbi 171
- Comfort conv settings 171
- Monitor climate audio phone and voice recognition systems 171
- 11 14 07 debbi 172
- Monitor climate audio phone and voice recognition systems 172
- Others settings models with navigation system 172
- 11 14 07 debbi 173
- How to use aux button 173
- Language units settings models without navigation system 173
- Monitor climate audio phone and voice recognition systems 173
- 11 14 07 debbi 174
- Display mode 174
- How to use disc button for models without navigation system 174
- Rearview monitor if so equipped 174
- 11 14 07 debbi 175
- How to park with predicted course lines 175
- How to read the displayed lines 175
- 11 14 07 debbi 176
- Monitor climate audio phone and voice recognition systems 176
- 11 14 07 debbi 177
- Backing up on a steep uphill 177
- Difference between predicted and actual distances 177
- 11 14 07 debbi 178
- Backing up on a steep downhill 178
- 11 14 07 debbi 179
- Backing up behind a projecting object 179
- Backing up near a projecting object 179
- How to adjust the screen 179
- Operating tips 179
- 11 14 07 debbi 180
- Around view monitor if so equipped 180
- Monitor climate audio phone and voice recognition systems 180
- 11 14 07 debbi 181
- Caution 181
- Monitor climate audio phone and voice recognition systems 181
- Warning 181
- 11 14 07 debbi 182
- How to switch the display 182
- Starting with the selector lever operation 182
- 11 14 07 debbi 183
- How to see each view 183
- Starting with the camera button operation 183
- 11 14 07 debbi 184
- Front and rear view 184
- 11 14 07 debbi 185
- Bird eye view 185
- Front side view 185
- 11 14 07 debbi 186
- Difference between predicted and actual distances 186
- Moving to a steep uphill 186
- 11 14 07 debbi 187
- Moving near a projecting object 187
- Moving to a steep downhill 187
- 11 14 07 debbi 188
- Camera aiding corner sonar function 188
- Moving closer to a projecting object 188
- 11 14 07 debbi 189
- Around view monitor settings 189
- Caution 189
- How to adjust the screen view 189
- Monitor climate audio phone and voice recognition systems 189
- Operating tips 189
- 11 14 07 debbi 190
- Monitor climate audio phone and voice recognition systems 190
- Ventilators 190
- 11 14 07 debbi 191
- Automatic climate control 191
- Monitor climate audio phone and voice recognition systems 191
- Warning 191
- 11 14 07 debbi 192
- Automatic climate control type a 192
- Automatic operation 192
- Monitor climate audio phone and voice recognition systems 192
- 11 14 07 debbi 193
- Manual operation 193
- Monitor climate audio phone and voice recognition systems 193
- 11 14 07 debbi 194
- Automatic climate control type b 194
- Automatic operation 194
- Monitor climate audio phone and voice recognition systems 194
- 11 14 07 debbi 195
- Manual operation 195
- Monitor climate audio phone and voice recognition systems 195
- 11 14 07 debbi 196
- In cabin microfilter 196
- Servicing climate control 196
- 11 14 07 debbi 197
- Audio operation precautions radio 197
- Audio system 197
- 11 14 07 debbi 198
- Compact disc cd player 198
- Monitor climate audio phone and voice recognition systems 198
- 11 14 07 debbi 199
- Compactflash cf player 199
- Ipod player if so equipped 199
- Monitor climate audio phone and voice recognition systems 199
- 11 14 07 debbi 200
- Compact disc cd compactflash cf with mp3 or wma 200
- Monitor climate audio phone and voice recognition systems 200
- 11 14 07 debbi 201
- Monitor climate audio phone and voice recognition systems 201
- 1 files created with a combination of 48 khz sampling frequency and 64 kbps bit rate cannot be played 2 protected wma files drm cannot be played 3 available codes depend on what kind of media versions and information are going to be displayed 4 when vbr files are played the playback time may not be displayed correctly 202
- 11 14 07 debbi 202
- Monitor climate audio phone and voice recognition systems 202
- Specification chart 202
- 11 14 07 debbi 203
- Monitor climate audio phone and voice recognition systems 203
- Troubleshooting guide 203
- 11 14 07 debbi 204
- Monitor climate audio phone and voice recognition systems 204
- 11 14 07 debbi 205
- Audio main operation 205
- Fm am sat radio with compact disc cd changer 205
- Monitor climate audio phone and voice recognition systems 205
- 11 14 07 debbi 206
- Fm am sat radio operation 206
- Monitor climate audio phone and voice recognition systems 206
- 11 14 07 debbi 207
- Compact disc cd player changer operation 207
- 11 14 07 debbi 208
- Monitor climate audio phone and voice recognition systems 208
- 11 14 07 debbi 209
- Audio main operation 209
- Compactflash cf player operation models with navigation system 209
- 11 14 07 debbi 210
- Compatibility 210
- Connecting ipod 210
- Ipod player operation if so equipped 210
- 11 14 07 debbi 211
- Audio main operation 211
- Monitor climate audio phone and voice recognition systems 211
- Music box hard drive models with navigation system 211
- 11 14 07 debbi 212
- Monitor climate audio phone and voice recognition systems 212
- Recording songs 212
- 11 14 07 debbi 213
- Monitor climate audio phone and voice recognition systems 213
- Playing recorded songs 213
- 11 14 07 debbi 214
- Monitor climate audio phone and voice recognition systems 214
- 11 14 07 debbi 215
- Monitor climate audio phone and voice recognition systems 215
- 11 14 07 debbi 216
- Monitor climate audio phone and voice recognition systems 216
- Restoring deleted data 216
- 11 14 07 debbi 217
- Gracenote 217
- Monitor climate audio phone and voice recognition systems 217
- Music box settings 217
- 11 14 07 debbi 218
- Cd cf compactflash care and cleaning 218
- Monitor climate audio phone and voice recognition systems 218
- 11 14 07 debbi 219
- Cf cards 219
- Monitor climate audio phone and voice recognition systems 219
- 11 14 07 debbi 220
- Enter models with navigation system or tuning models without navigation system switch 220
- Monitor climate audio phone and voice recognition systems 220
- Steering wheel mounted controls for audio 220
- 11 27 07 patti 221
- Antenna window antenna 221
- Back switch 221
- Caution 221
- Monitor climate audio phone and voice recognition systems 221
- Roof antenna 221
- Source select switch 221
- Volume control switches 221
- 11 14 07 debbi 222
- Auxiliary input jacks 222
- Car phone or cb radio 222
- 11 14 07 debbi 223
- Bluetooth hands free phone system with navigation system for u s 223
- Caution 223
- Monitor climate audio phone and voice recognition systems 223
- Warning 223
- 11 14 07 debbi 224
- Fcc regulatory information 224
- Ic regulatory information 224
- Monitor climate audio phone and voice recognition systems 224
- Regulatory information 224
- Voice commands 224
- 11 14 07 debbi 225
- Control buttons 225
- Monitor climate audio phone and voice recognition systems 225
- Pairing procedure 225
- 11 14 07 debbi 226
- Monitor climate audio phone and voice recognition systems 226
- Phonebook registration 226
- 11 14 07 debbi 227
- After the memory is registered in the phonebook the system will ask if you want to add a voicetag for it if you want to add a voicetag select the yes key on the add a voicetag screen for ex ample if the partner s name is david speak david after a tone the david voicetag is stored in the phonebook voic etags allow easy dialing using the infiniti voice recognition system see infiniti voice recognition system models with navigation system later in this sec tion page 4 104 227
- Monitor climate audio phone and voice recognition systems 227
- Select the transfer via bluetooth key and push the enter button in order to register your cellular phone memory in the phonebook 5 operate the cellular phone to send a person s name and phone number from the memory of the cellular phone the memory sending procedure from the cel lular phone varies according to each cel lular phone manufacturer see the cellular phone owner s manual for more details 227
- When the phonebook registration is com pleted the screen will return to the name list of the phonebook 227
- 11 14 07 debbi 228
- Making a call 228
- Monitor climate audio phone and voice recognition systems 228
- 11 14 07 debbi 229
- During a call 229
- Monitor climate audio phone and voice recognition systems 229
- Receiving a call 229
- 11 14 07 debbi 230
- Downloaded phonebook 230
- Monitor climate audio phone and voice recognition systems 230
- Phone setting 230
- Phonebook 230
- 11 14 07 debbi 231
- Automatic hold 231
- Bluetooth setup 231
- Delete call logs 231
- Monitor climate audio phone and voice recognition systems 231
- Use vehicle ringtone 231
- 11 14 07 debbi 232
- Monitor climate audio phone and voice recognition systems 232
- Troubleshooting guide 232
- 11 14 07 debbi 233
- Bluetooth hands free phone system with navigation system for canada 233
- Caution 233
- Monitor climate audio phone and voice recognition systems 233
- Warning 233
- 11 14 07 debbi 234
- Fcc regulatory information 234
- Ic regulatory information 234
- Monitor climate audio phone and voice recognition systems 234
- Regulatory information 234
- Voice commands 234
- 11 14 07 debbi 235
- Control buttons 235
- Monitor climate audio phone and voice recognition systems 235
- Pairing procedure 235
- 11 14 07 debbi 236
- Monitor climate audio phone and voice recognition systems 236
- 11 14 07 debbi 237
- Monitor climate audio phone and voice recognition systems 237
- Phonebook registration 237
- 11 14 07 debbi 238
- Making a call 238
- Monitor climate audio phone and voice recognition systems 238
- 11 14 07 debbi 239
- Monitor climate audio phone and voice recognition systems 239
- Receiving a call 239
- 11 14 07 debbi 240
- During a call 240
- Monitor climate audio phone and voice recognition systems 240
- Phone setting 240
- Phonebook 240
- 11 14 07 debbi 241
- Automatic hold 241
- Bluetooth setup 241
- Delete call logs 241
- Downloaded phonebook 241
- Monitor climate audio phone and voice recognition systems 241
- Use vehicle ringtone 241
- 11 14 07 debbi 242
- Monitor climate audio phone and voice recognition systems 242
- 11 14 07 debbi 243
- Monitor climate audio phone and voice recognition systems 243
- Troubleshooting guide 243
- 11 14 07 debbi 244
- Bluetooth hands free phone system without navigation system 244
- Caution 244
- Monitor climate audio phone and voice recognition systems 244
- Warning 244
- 11 14 07 debbi 245
- Fcc regulatory information 245
- Ic regulatory information 245
- Initialization 245
- Monitor climate audio phone and voice recognition systems 245
- Operating tips 245
- Regulatory information 245
- 11 14 07 debbi 246
- Giving voice commands 246
- How to say numbers 246
- Monitor climate audio phone and voice recognition systems 246
- 11 14 07 debbi 247
- Choosing a language 247
- Control buttons 247
- Getting started 247
- Pairing procedure 247
- 11 14 07 debbi 248
- Making a call by entering a phone number 248
- Receiving a call 248
- 11 14 07 debbi 249
- List of voice commands 249
- Monitor climate audio phone and voice recognition systems 249
- 11 14 07 debbi 250
- Monitor climate audio phone and voice recognition systems 250
- 11 14 07 debbi 251
- Monitor climate audio phone and voice recognition systems 251
- Phone book 251
- 11 14 07 debbi 252
- Monitor climate audio phone and voice recognition systems 252
- 11 14 07 debbi 253
- Memo pad 253
- Monitor climate audio phone and voice recognition systems 253
- 11 14 07 debbi 254
- Monitor climate audio phone and voice recognition systems 254
- 11 14 07 debbi 255
- Monitor climate audio phone and voice recognition systems 255
- Speaker adaptation sa mode 255
- Training phrases 255
- Training procedure 255
- 11 14 07 debbi 256
- Monitor climate audio phone and voice recognition systems 256
- 11 14 07 debbi 257
- Monitor climate audio phone and voice recognition systems 257
- Troubleshooting guide 257
- 11 14 07 debbi 258
- Displaying user guide 258
- Infiniti voice recognition standard mode 258
- Infiniti voice recognition system models with navigation system for u s 258
- 11 14 07 debbi 259
- Getting started 259
- Monitor climate audio phone and voice recognition systems 259
- 11 14 07 debbi 260
- Initialization 260
- Monitor climate audio phone and voice recognition systems 260
- Useful tips for correct operation 260
- Using the system 260
- Voice recognition settings 260
- 11 14 07 debbi 261
- Before starting 261
- Giving voice commands 261
- Monitor climate audio phone and voice recognition systems 261
- 11 14 07 debbi 262
- How to speak numbers 262
- Monitor climate audio phone and voice recognition systems 262
- Operating tips 262
- 11 14 07 debbi 263
- Command list 263
- Monitor climate audio phone and voice recognition systems 263
- 11 14 07 debbi 264
- Information command 264
- Monitor climate audio phone and voice recognition systems 264
- 11 14 07 debbi 265
- Monitor climate audio phone and voice recognition systems 265
- Voice command examples 265
- 11 14 07 debbi 266
- Monitor climate audio phone and voice recognition systems 266
- 11 14 07 debbi 267
- Monitor climate audio phone and voice recognition systems 267
- The system announces dial or change number 11 speak dial 12 the system makes a call to 800 620 6200 267
- The system announces please say the last four digits or say change number 9 speak 6200 267
- 11 14 07 debbi 268
- Monitor climate audio phone and voice recognition systems 268
- 11 14 07 debbi 269
- Infiniti voice recognition alternate command mode 269
- Monitor climate audio phone and voice recognition systems 269
- 11 14 07 debbi 270
- Activating alternate command mode 270
- Displaying command list 270
- Monitor climate audio phone and voice recognition systems 270
- 11 14 07 debbi 271
- Monitor climate audio phone and voice recognition systems 271
- 11 14 07 debbi 272
- List of help commands 272
- Monitor climate audio phone and voice recognition systems 272
- 11 14 07 debbi 273
- Monitor climate audio phone and voice recognition systems 273
- Satellite 273
- Vehicle information commands 273
- 11 14 07 debbi 274
- Climate commands 274
- Monitor climate audio phone and voice recognition systems 274
- 11 14 07 debbi 275
- Displaying user guide 275
- Monitor climate audio phone and voice recognition systems 275
- 11 14 07 debbi 276
- Before starting 276
- Giving voice command 276
- Initialization 276
- Monitor climate audio phone and voice recognition systems 276
- Using the system 276
- 11 16 07 tbrook 277
- How to speak numbers 277
- Monitor climate audio phone and voice recognition systems 277
- Operating tips 277
- 11 14 07 debbi 278
- Having the system learn the user s voice 278
- Monitor climate audio phone and voice recognition systems 278
- Speaker adaptation function 278
- 11 14 07 debbi 279
- Monitor climate audio phone and voice recognition systems 279
- Select a category to be learned by the system from the following list and then push the enter button 279
- Select a voice command and then push the enter button 279
- Speak the command that the system re quested 9 when the system has recognized the voice command the voice of the user is learned 279
- The system requests that you repeat a command after a tone 8 after the tone sounds and the icon on the screen changes from 279
- 11 14 07 debbi 280
- Minimize voice feedback 280
- Monitor climate audio phone and voice recognition systems 280
- Speaker adaptation function settings 280
- 11 14 07 debbi 281
- Monitor climate audio phone and voice recognition systems 281
- Troubleshooting guide 281
- 11 14 07 debbi 282
- Command list 282
- Displaying command list 282
- Infiniti voice recognition system models with navigation system for canada 282
- 11 14 07 debbi 283
- Monitor climate audio phone and voice recognition systems 283
- 11 14 07 debbi 284
- List of help commands 284
- Monitor climate audio phone and voice recognition systems 284
- 11 14 07 debbi 285
- Monitor climate audio phone and voice recognition systems 285
- Radio off and radio menu commands are available when the radio mode is selected 285
- 11 14 07 debbi 286
- Monitor climate audio phone and voice recognition systems 286
- Note cd commands except cd play are available when the cd mode is selected 286
- Note radio off and radio menu commands are available when the radio mode is selected 286
- Satellite 286
- 11 14 07 debbi 287
- Cf commands except compact flash play are available when the cf mode is selected 287
- Monitor climate audio phone and voice recognition systems 287
- 11 14 07 debbi 288
- Climate control help 288
- Monitor climate audio phone and voice recognition systems 288
- Phone help 288
- 11 14 07 debbi 289
- Monitor climate audio phone and voice recognition systems 289
- Others help 289
- Vehicle 289
- 11 14 07 debbi 290
- Displaying user guide 290
- Initialization 290
- Monitor climate audio phone and voice recognition systems 290
- Using the system 290
- 11 14 07 debbi 291
- Before starting 291
- Giving voice command 291
- Monitor climate audio phone and voice recognition systems 291
- 11 14 07 debbi 292
- How to speak numbers 292
- Monitor climate audio phone and voice recognition systems 292
- Operating tips 292
- 11 14 07 debbi 293
- Having the system learn the user s voice 293
- Monitor climate audio phone and voice recognition systems 293
- Personal vocabulary voicetags 293
- Voice command learning function 293
- 11 14 07 debbi 294
- Monitor climate audio phone and voice recognition systems 294
- 11 14 07 debbi 295
- Learning function settings 295
- Monitor climate audio phone and voice recognition systems 295
- 11 14 07 debbi 296
- Monitor climate audio phone and voice recognition systems 296
- 11 14 07 debbi 297
- Monitor climate audio phone and voice recognition systems 297
- Troubleshooting guide 297
- 11 14 07 debbi 298
- Starting and driving 298
- 11 14 07 debbi 299
- 11 14 07 debbi 300
- Exhaust gas carbon monoxide 300
- Precautions when starting and driving 300
- Three way catalyst 300
- 11 14 07 debbi 301
- Additional information 301
- Starting and driving 301
- Tire pressure monitoring system tpms 301
- 11 14 07 debbi 302
- Caution 302
- Starting and driving 302
- Warning 302
- 11 14 07 debbi 303
- Avoiding collision and rollover 303
- Drinking alcohol drugs and driving 303
- Starting and driving 303
- Warning 303
- 11 14 07 debbi 304
- All wheel drive awd driving safety precautions for awd models 304
- Push button ignition switch 304
- 11 14 07 debbi 305
- Operating range for engine start function 305
- 11 14 07 debbi 306
- Acc accessories 306
- Intelligent key battery discharge 306
- Lock normal parking position 306
- On normal operating position 306
- Push button ignition switch positions 306
- 11 14 07 debbi 307
- Before starting the engine starting the engine 307
- Caution 307
- Starting and driving 307
- 11 14 07 debbi 308
- Automatic transmission 5 speed automatic transmission 308
- Driving the vehicle 308
- Starting the vehicle 308
- 11 14 07 debbi 309
- Caution 309
- Shifting 309
- Starting and driving 309
- Warning 309
- 11 14 07 debbi 310
- Caution 310
- Ds drive sport mode 310
- Manual shift mode 310
- Starting and driving 310
- 11 14 07 debbi 311
- Accelerator downshift in d drive position 311
- Fail safe 311
- Shift lock release 311
- 11 14 07 debbi 312
- Automatic transmission models 312
- 11 14 07 debbi 313
- Lane departure warning ldw system lane departure prevention ldp system if so equipped 313
- 11 14 07 debbi 314
- Lane departure warning ldw system 314
- Precautions on ldw system 314
- Starting and driving 314
- Warning 314
- 11 14 07 debbi 315
- Ldw system operation 315
- Temporary disabled status at high temperature 315
- 11 14 07 debbi 316
- Lane departure prevention ldp system 316
- Precautions on ldp system 316
- Starting and driving 316
- Warning 316
- 11 14 07 debbi 317
- Ldp system operation 317
- Starting and driving 317
- 11 14 07 debbi 318
- Automatic deactivation 318
- Starting and driving 318
- 11 14 07 debbi 319
- Lane camera unit maintenance 319
- Precautions on cruise control 319
- 11 14 07 debbi 320
- Cruise control operations 320
- Starting and driving 320
- 11 14 07 debbi 321
- Intelligent cruise control icc system if so equipped 321
- Starting and driving 321
- Warning 321
- 11 14 07 debbi 322
- Selecting the vehicle to vehicle distance control mode 322
- 11 14 07 debbi 323
- Precautions on vehicle to vehicle distance control mode 323
- Vehicle to vehicle distance control mode 323
- 11 14 07 debbi 324
- Starting and driving 324
- Warning 324
- 11 14 07 debbi 325
- Vehicle to vehicle distance control mode operation 325
- 11 14 07 debbi 326
- Starting and driving 326
- 11 14 07 debbi 327
- Starting and driving 327
- 11 14 07 debbi 328
- Intelligent cruise control switch 328
- Intelligent cruise control system display and indicators 328
- Starting and driving 328
- 11 14 07 debbi 329
- Operating vehicle to vehicle distance control mode 329
- 11 14 07 debbi 330
- Starting and driving 330
- 11 14 07 debbi 331
- Starting and driving 331
- System operation 331
- Warning 331
- 11 14 07 debbi 332
- How to change the set vehicle speed 332
- Starting and driving 332
- 11 14 07 debbi 333
- How to change the set distance to the vehicle ahead 333
- 11 14 07 debbi 334
- Approach warning 334
- Starting and driving 334
- 11 14 07 debbi 335
- Automatic cancellation 335
- Warning light and display 335
- 11 14 07 debbi 336
- Starting and driving 336
- 11 14 07 debbi 337
- Conventional fixed speed cruise control mode 337
- Sensor maintenance 337
- 11 14 07 debbi 338
- Conventional fixed speed cruise control mode display and indicators 338
- Conventional fixed speed cruise control switch 338
- Starting and driving 338
- 11 14 07 debbi 339
- Operating conventional fixed speed cruise control mode 339
- 11 14 07 debbi 340
- Automatic cancellation 340
- Starting and driving 340
- 11 14 07 debbi 341
- Break in schedule 341
- Preview function for intelligent cruise control system equipped models 341
- Warning light 341
- 11 14 07 debbi 342
- Increasing fuel economy all wheel drive awd if so equipped 342
- Starting and driving 342
- 11 14 07 debbi 343
- Caution 343
- Starting and driving 343
- Warning 343
- 11 14 07 debbi 344
- Parking parking on hills 344
- 11 14 07 debbi 345
- Caution 345
- Sonar system if so equipped 345
- Starting and driving 345
- Warning 345
- 11 14 07 debbi 346
- Braking precautions 346
- Sonar system off switch 346
- Vacuum assisted brakes 346
- Wet brakes 346
- 11 14 07 debbi 347
- Brake assist 347
- Parking brake break in 347
- Preview function intelligent cruise control system equipped models 347
- Using the brakes 347
- 11 14 07 debbi 348
- Starting and driving 348
- Warning 348
- 11 14 07 debbi 349
- How to handle the sensor 349
- Starting and driving 349
- Warning light and display 349
- 11 14 07 debbi 350
- Anti lock braking system abs 350
- Normal operation 350
- Self test feature 350
- Starting and driving 350
- Using the system 350
- Warning 350
- 11 14 07 debbi 351
- Starting and driving 351
- Vehicle dynamic control vdc system 351
- 11 14 07 debbi 352
- Antifreeze 352
- Battery 352
- Cold weather driving 352
- Draining of coolant water 352
- Freeing a frozen door lock 352
- 11 14 07 debbi 353
- Driving on snow or ice 353
- Engine block heater if so equipped 353
- For all wheel drive 353
- Special winter equipment 353
- Starting and driving 353
- Tire equipment 353
- Warning 353
- 11 14 07 debbi 354
- Starting and driving 354
- To use the engine block heater 354
- Warning 354
- 11 14 07 debbi 355
- In case of emergency 355
- 11 14 07 debbi 356
- Roadside assistance program flat tire 356
- Tire pressure monitoring system tpms 356
- 11 14 07 debbi 357
- Blocking wheels 357
- Changing a flat tire 357
- Stopping the vehicle 357
- 11 14 07 debbi 358
- Getting the spare tire and tools 358
- Jacking up the vehicle and removing the damaged tire 358
- 11 14 07 debbi 359
- In case of emergency 359
- 11 14 07 debbi 360
- Installing the spare tire 360
- Stowing the damaged tire and tools 360
- 11 14 07 debbi 361
- In case of emergency 361
- Jump starting 361
- Warning 361
- 11 14 07 debbi 362
- Caution 362
- In case of emergency 362
- Warning 362
- 11 14 07 debbi 363
- Push starting if your vehicle overheats 363
- 11 14 07 debbi 364
- Caution 364
- In case of emergency 364
- Towing your vehicle 364
- Warning 364
- 11 14 07 debbi 365
- Caution 365
- In case of emergency 365
- Towing recommended by infiniti 365
- Two wheel drive 2wd models 365
- 11 14 07 debbi 366
- All wheel drive awd models 366
- Caution 366
- In case of emergency 366
- 11 14 07 debbi 367
- Pulling a stuck vehicle 367
- Rocking a stuck vehicle 367
- Vehicle recovery freeing a stuck vehicle 367
- 11 14 07 debbi 368
- If the vehicle cannot be freed after a few tries contact a professional towing ser vice to remove the vehicle 368
- In case of emergency 368
- Turn the steering wheel right and left to clear an area around the front tires 4 slowly rock the vehicle forward and back ward 368
- 11 14 07 debbi 369
- Appearance and care 369
- 11 14 07 debbi 370
- Cleaning exterior 370
- Washing 370
- Waxing 370
- 11 14 07 debbi 371
- Aluminum alloy wheels 371
- Appearance and care 371
- Caution 371
- Chrome parts 371
- Removing spots 371
- Tire dressing 371
- Underbody 371
- 11 14 07 debbi 372
- Cleaning interior 372
- Floor mat positioning aid 372
- Floor mats 372
- 11 14 07 debbi 373
- Air pollution 373
- Corrosion protection 373
- Environmental factors influence the rate of corrosion 373
- Moisture 373
- Most common factors contributing to vehicle corrosion 373
- Relative humidity 373
- Seat belts 373
- Temperature 373
- To protect your vehicle from corrosion 373
- 11 14 07 debbi 374
- Appearance and care 374
- Caution 374
- 11 14 07 debbi 375
- Maintenance and do it yourself 375
- 11 14 07 debbi 376
- Explanation of maintenance items 376
- General maintenance 376
- Maintenance requirement general maintenance 376
- Outside the vehicle 376
- Scheduled maintenance 376
- Where to go for service 376
- 11 14 07 debbi 377
- Inside the vehicle 377
- Maintenance and do it yourself 377
- 11 14 07 debbi 378
- Maintenance and do it yourself 378
- Under the hood and vehicle 378
- 11 14 07 debbi 379
- Caution 379
- Maintenance and do it yourself 379
- Maintenance precautions 379
- Warning 379
- 11 14 07 debbi 380
- Engine compartment check locations 380
- Vq35hr engine 380
- 11 14 07 debbi 381
- Checking engine coolant level 381
- 11 14 07 debbi 382
- Changing engine coolant 382
- Changing engine oil and filter 382
- Checking engine oil level 382
- Vehicle set up 382
- 11 14 07 debbi 383
- Engine oil and filter 383
- 11 14 07 debbi 384
- After the operation 384
- Caution 384
- Maintenance and do it yourself 384
- Warning 384
- 11 14 07 debbi 385
- Automatic transmission fluid power steering fluid 385
- 11 14 07 debbi 386
- Brake fluid 386
- 11 14 07 debbi 387
- Battery 387
- Caution 387
- Maintenance and do it yourself 387
- Warning 387
- 11 14 07 debbi 388
- Jump starting 388
- 11 14 07 debbi 389
- Caution 389
- Maintenance and do it yourself 389
- Variable voltage control system drive belts 389
- Warning 389
- 11 14 07 debbi 390
- Iridium tipped spark plugs 390
- Replacing spark plugs 390
- 11 14 07 debbi 391
- Cleaning 391
- Windshield wiper blades 391
- 11 14 07 debbi 392
- Replacing 392
- 11 14 07 debbi 393
- Brake pad wear indicators 393
- Rear window wiper blades brakes 393
- Self adjusting brakes 393
- 11 14 07 debbi 394
- Engine compartment 394
- Fusible links 394
- 11 14 07 debbi 395
- Passenger compartment 395
- 11 14 07 debbi 396
- Align the tips of the upper and lower parts and then push them together until it is securely closed 396
- Maintenance and do it yourself 396
- Push the buttons two or three times to check its operation 396
- Replace the battery with a new one 396
- 11 14 07 debbi 397
- Lights 397
- Maintenance and do it yourself 397
- 11 16 07 tbrook 398
- Caution 398
- Headlights replacing 398
- High voltage 398
- Maintenance and do it yourself 398
- Warning 398
- 11 14 07 debbi 399
- Exterior and interior lights 399
- Maintenance and do it yourself 399
- Replacement procedures 399
- 11 14 07 debbi 400
- Cargo light 400
- Maintenance and do it yourself 400
- Map light 400
- Rear personal light 400
- Vanity mirror light 400
- Tire inflation pressure 401
- Tire pressure 401
- Tire pressure monitoring system tpms 401
- Tire and loading information label 402
- Checking the tire pressure 403
- Tire labeling 404
- All season tires 406
- Summer tires 406
- Types of tires 406
- 11 14 07 debbi 407
- Maintenance and do it yourself 407
- Snow tires 407
- Tire chains 407
- Changing wheels and tires 408
- Tire rotation 408
- Tire wear and damage 408
- 11 14 07 debbi 409
- For additional information regarding tires refer to important tire safety information us or tire safety in formation canada in the warranty information booklet 409
- Improper service of the spare tire may result in serious personal injury if it is necessary to repair the spare tire contact an infiniti dealer 409
- Maintenance and do it yourself 409
- Replacing wheels and tires 409
- The original tires have built in tread wear indicators when wear indica tors are visible the tire s should be replaced 409
- Tires degrade with age and use have tires including the spare over 6 years old checked by a qualified tech nician because some tire damage may not be obvious replace the tires as necessary to prevent tire failure and possible personal injury 409
- Warning 409
- 11 14 07 debbi 410
- All wheel drive awd models 410
- Care of wheels 410
- Caution 410
- Maintenance and do it yourself 410
- Spare tire temporary use only t type spare tire 410
- Warning 410
- Wheel balance 410
- 11 14 07 debbi 411
- Caution 411
- Maintenance and do it yourself 411
- 11 14 07 debbi 413
- Technical and consumer information 413
- 11 14 07 debbi 414
- Capacities and recommended fuel lubricants 414
- Technical and consumer information 414
- 11 14 07 debbi 415
- Caution 415
- Fuel recommendation vq35hr engine 415
- Gasoline containing oxygenates 415
- Gasoline specifications 415
- Reformulated gasoline 415
- Technical and consumer information 415
- 11 14 07 debbi 416
- Aftermarket fuel additives 416
- E 85 fuel 416
- Octane rating tips 416
- Technical and consumer information 416
- 11 14 07 debbi 417
- Change intervals 417
- Engine oil and oil filter recommendation 417
- Oil additives 417
- Oil viscosity 417
- Selecting the correct oil 417
- Selecting the correct oil filter 417
- Technical and consumer information 417
- 11 14 07 debbi 418
- Air conditioning system refrigerant and lubricant recommendations 418
- Caution 418
- Technical and consumer information 418
- 11 14 07 debbi 419
- Engine 419
- Specifications 419
- 11 14 07 debbi 420
- Road wheel 420
- Technical and consumer information 420
- Wheels and tires 420
- 11 14 07 debbi 421
- Dimensions 421
- When traveling or registering your vehicle in another country 421
- 11 14 07 debbi 422
- Engine serial number 422
- Vehicle identification 422
- Vehicle identification number chassis number 422
- Vehicle identification number vin plate 422
- 11 14 07 debbi 423
- Emission control information label 423
- F m v s s c m v s s certification label 423
- Technical and consumer information 423
- Tire and loading information label 423
- Air conditioner specification label 424
- 11 14 07 debbi 425
- Be sure everyone in your vehicle is in a seat and using a seat belt properly 425
- Curb weight actual weight of your vehicle vehicle weight including standard and optional equipment flu ids emergency tools and spare tire assembly this weight does no 425
- Do not allow people to ride in any area of vehicle that is not equipped with seats and seat belts 425
- It is extremely dangerous to ride in a cargo area inside the vehicle in a col lision people riding in these areas are more likely to be seriously injured or killed 425
- It is important to familiarize yourself with the following terms before loading your vehicle 425
- Steps for determining correct load limit 427
- Vehicle load capacity 427
- Loading tips 428
- Measurement of weights 428
- 11 27 07 patti 429
- Automatic transmission 429
- Flat towing 429
- Towing a trailer uniform tire quality grading 429
- Traction aa a b and c 429
- Treadwear 429
- 11 14 07 debbi 430
- Emission control system warranty 430
- Temperature a b and c 430
- 11 14 07 debbi 432
- Event data recorders 432
- Technical and consumer information 432
- Warning 432
- 11 14 07 debbi 433
- In the event of a collision 433
- Owner s manual service manual order information 433
- 11 14 07 debbi 434
- Insist on the use of genuine infiniti collision parts 434
- It s your right 434
- Technical and consumer information 434
- Why should you take a chance 434
- 11 14 07 debbi 435
- 11 14 07 debbi 436
- 11 15 07 debbi 437
- 11 14 07 debbi 438
- 11 14 07 debbi 439
- 11 14 07 debbi 440
- 11 14 07 debbi 441
- 11 14 07 debbi 447
- Cold tire pressures 447
- Engine oil recommendation 447
- Fuel recommendation vq35hr engine 447
- Gas station information 447
- New vehicle break in procedures recommendation 447
- 11 14 07 debbi 448
Похожие устройства
- Infiniti EX35 (2009) Руководство по эксплуатации
- Infiniti EX35 (2010) Руководство по эксплуатации
- Infiniti M35 (2007) Руководство по эксплуатации
- Infiniti M45 (2007) Руководство по эксплуатации
- Infiniti M35 (2008) Руководство по эксплуатации
- Infiniti M45 (2008) Руководство по эксплуатации
- Infiniti M35 (2009) Руководство по эксплуатации
- Infiniti M45 (2009) Руководство по эксплуатации
- Infiniti M35 (2010) Руководство по эксплуатации
- Infiniti M45 (2010) Руководство по эксплуатации
- Infiniti M37 (2011) Руководство по эксплуатации
- Infiniti FX50 (2009) Руководство по эксплуатации
- Infiniti FX35 (2009) Руководство по эксплуатации
- Infiniti FX50 (2010) Руководство по эксплуатации
- Infiniti M56 (2011) Руководство по эксплуатации
- CADILLAC SRX CROSSOVER (2009) Руководство по эксплуатации
- CADILLAC ESCALADE (2009) Руководство по эксплуатации
- CADILLAC CTS SEDAN (2010) Руководство по эксплуатации
- CADILLAC CTS-V SEDAN (2011) навигационная система Руководство по эксплуатации
- CADILLAC CTS-V SEDAN (2011) Руководство по эксплуатации
