Xiaomi Redmi Note 8 Pro 64Gb+6Gb Dual LTE [81/132] Game controller support
![Xiaomi Redmi Note 8 Pro 64Gb+6Gb Dual LTE [81/132] Game controller support](/views2/1987256/page81/bg51.png)
[C-2-2] MUST support distinct tracking of two or more independent pointer inputs.
If device implementations declare support for android.hardware.faketouch.multitouch.jazzhand , they:
[C-3-1] MUST declare support for android.hardware.faketouch .
[C-3-2] MUST support distinct tracking of 5 (tracking a hand of fingers) or more pointer
inputs fully independently.
7.2.6. Game Controller Support
7.2.6.1. Button Mappings
If device implementations declare the android.hardware.gamepad feature flag, they:
[C-1-1] MUST have embed a controller or ship with a separate controller in the box, that
would provide means to input all the events listed in the below tables.
[C-1-2] MUST be capable to map HID events to it's associated Android view.InputEvent
constants as listed in the below tables. The upstream Android implementation includes
implementation for game controllers that satisfies this requirement.
Button
HID Usage
2
Android Button
A
1
0x09 0x0001 KEYCODE_BUTTON_A (96)
B
1
0x09 0x0002 KEYCODE_BUTTON_B (97)
X
1
0x09 0x0004 KEYCODE_BUTTON_X (99)
Y
1
0x09 0x0005 KEYCODE_BUTTON_Y (100)
D-pad up
1
D-pad down
1
0x01 0x0039
3
AXIS_HAT_Y
4
D-pad left 1
D-pad right
1
0x01 0x0039
3
AXIS_HAT_X
4
Left shoulder button
1
0x09 0x0007 KEYCODE_BUTTON_L1 (102)
Right shoulder button
1
0x09 0x0008 KEYCODE_BUTTON_R1 (103)
Left stick click
1
0x09 0x000E KEYCODE_BUTTON_THUMBL (106)
Right stick click
1
0x09 0x000F KEYCODE_BUTTON_THUMBR (107)
Home
1
0x0c 0x0223 KEYCODE_HOME (3)
Back
1
0x0c 0x0224 KEYCODE_BACK (4)
1 KeyEvent
2 The above HID usages must be declared within a Game pad CA (0x01 0x0005).
3 This usage must have a Logical Minimum of 0, a Logical Maximum of 7, a Physical Minimum of 0, a Physical
Maximum of 315, Units in Degrees, and a Report Size of 4. The logical value is defined to be the clockwise
rotation away from the vertical axis; for example, a logical value of 0 represents no rotation and the up button
being pressed, while a logical value of 1 represents a rotation of 45 degrees and both the up and left keys
being pressed.
4 MotionEvent
HID Usage Android Button
Page 81 of 132
