SOLID STATE LOGIC XLogic G Series Stereo Compressor [13/18] Appendix a internal links and fuses
![SOLID STATE LOGIC XLogic G Series Stereo Compressor [13/18] Appendix a internal links and fuses](/views2/1989591/page13/bgd.png)
Page 9
Appendix A – Internal links and fuses
Fuses (Mains Inlet)
The mains inlet contains a single 1 amp 1.25" time delay fuse (SSL Part No. 35FJJ310). To change it disconnect the
mains inlet, then using a small screwdriver prise open the mains selector cover. This contains the fuse. Test and
replace with the same type and value if necessary.
Internal Fuses
There are no internal power rail fuses.
Links
TP5 Wire link. 0V test point.
LK1 Wire link. Connects –18V rail from the PSU to the compressor. Do not remove.
LK2 Wire link. Connects +18V rail from the PSU to the compressor. Do not remove.
LK3 VCA Track. Selects which channel to trim when balancing the VCA control voltages.
LK4, LK5 Normally audio passes through the VCAs at all times. Fitting these links in the ‘Hard’ position will
switch in the bypass relays when the Compressor IN switch is off. Normally both links are fitted in
the ‘Soft’ position.
Appendix B – Connector Details
Remote
Location:
Rear Panel
Conn' Type:
9-pin 'D' Type Female
Pin
Description
1
Meter +ve
2
Autofade Switch
3
Autofade Lamp +ve
4
n/c
5
n/c
6
Meter -ve
7
Autofade Switch
8
Autofade Lamp -ve
9
n/c
Key Input
Location:
Rear Panel
Conn' Type:
XLR Female
Pin
Description
1
Chassis
2
Audio +ve
3
Audio -ve
Audio Output
Location:
Rear Panel
Conn' Type:
XLR Male
Pin
Description
1
Chassis
2
Audio +ve
3
Audio -ve
Audio Input
Location:
Rear Panel
Conn' Type:
XLR Female
Pin
Description
1
Chassis
2
Audio +ve
3
Audio -ve
