Appendix E – Physical specification *

Depth: 350mm / 13.8 inches

425mm / 16.75 inches including connectors

Height: 44.5mm / 1.75 inches (1 RU)

Width: 480mm / 19 inches

Weight: 3.3kg / 7.5 pounds

Power: 23 Watts / 29VA

Boxed size: 520mm x 520mm x 182mm (20.5" x 20.5" x 7.2")

Boxed weight: 5.6kg / 12.5 pounds

* All weights and dimensions are approximate

Appendix F – Environmental Specification

Temperature Operating: 5 to 30 Deg. C

Non-operating: –20 to 50 Deg. C

Max. gradient: 15 Deg. C/Hour

Relative Humidity Operating: 20 to 80 %

Non-operating: 5 to 90 %

Max. wet bulb: 29 Deg. C (non-condensing)

Vibration Operating: < 0.2 G (3 - 100Hz)

Non-operating, power off: < 0.4 G (3 - 100Hz)

Shock Operating: < 2 G (10mSec. Max.)

Non-operating: < 10 G (10mSec. Max.)

Altitude Operating: 0 to 3000m (above sea level)

Non-operating: 0 to 12000m
