NX L23-A GROUND STACKED
NX L23-A loudspeakers can be stacked
on top of NX subwoofers with the optional
AC STACKING / NX L23-A adapters.
1) Insert the optional AC STACKING / NX
L23-A adapters on subs as shown in the
picture.
english
21
2) The AC STACKING / NX L23-A adds a
fixed amount of up or downtilt to ground-
stacked NX L23-A loudspeakers, with
additional 17,5 degrees of adjustment
possible (from +10° to -7,5°).
