RCF EVOX 8 [11/24] Specifications

ENGLISH

EVOX 5 EVOX 8

ACOUSTICAL

Frequency response 45 Hz ÷ 20 kHz 40 Hz ÷ 20 kHz

Maximum sound pressure level 125 dB 128 dB

Horizontal coverage angle 120° 120°

Vertical coverage angle 30° 30°

Subwoofer transducers 10” (2.0” voice coil) 12” (2.5” voice coil)

Satellite transducers 5 x 2” (1.0” voice coil) 8 x 2” (1.0” voice coil)

AMPLIFIER / DSP

Amplier power (low frequencies) 600 W (peak) 1000 W (peak)

Amplier power (high frequencies) 200 W (peak) 400 W (peak)

Input sensitivity (LINE) +4 dBu +4 dBu

Crossover frequency 220 Hz 220 Hz

Protections thermal drift, RMS thermal drift, RMS

Limiter software limiter software limiter

Cooling convective convective

Operating voltage

115 / 230 V (according to the model),

50-60 Hz

115 / 230 V (according to the model),

50-60 Hz

Inrush current

10,1 A

(According to EN 55013-1: 2009)

10,1 A

(According to EN 55013-1: 2009)

SUBWOOFER PHYSICAL

Height 490 mm (19.29”) 530 mm (20.87”)

Width 288 mm (11.34”) 346 mm (13.62”)

Depth 427 mm (16.81”) 460 mm (18.10”)

Net weight 19.2 kg (42.33 lbs) 23.8 kg (52.47 lbs)

Cabinet Baltic birch plywood Baltic birch plywood

SPECIFICATIONS
