7
ENGLISH
Lift up the satellite speaker to remove it from
its subwoofer.
Screw the lower part of the satellite speaker
stand (the pole) into the subwoofer insert for
pole mounting.
Screw the central part of the satellite speaker
stand into its lower part, then insert the
telescopic upper part.
Loose the stand bolt, adjust the satellite
speaker height from the oor and tighten the
bolt again, then insert the satellite speaker
into its complete stand and aim it correctly.
INSTALLATION
