DLM12S Subwoofer: Rear Panel Features
1. Power Connection
Thisisastandard3-prongIECpowerconnector.
Connectthedetachablepowercord(includedin
thepackagingwiththesubwoofer)tothepower
receptacle,andplugtheotherendofthepower
cordintoanACoutlet.
MakesurethattheACpowerismatchedto
theACpowerindicatedontherearpanel
(totheleftoftheIECreceptacle).
Disconnectingtheplug’sgroundpinis
dangerous.Don’tdoit!
2. Power Switch
Pressthetopofthisrockerswitchinwardstoturn
onthesubwoofer.ThefrontpanelpowerLEDwillglow
withhappiness...oratleastitwillifthesubwooferis
pluggedintoasuitableliveACmainssupply.
Pressthebottomofthisrockerswitchinwardstoturn
offthesubwoofer.
Asageneralguide,themixer(orothersignal
source)shouldbeturnedonrst,DLM12S
subwoofersnext,andloudspeakerslast.
Assuch,theloudspeakersshouldalsobeturnedoffrst,
followedbythesubwoofers,thenthemixer.Thiswill
reducethepossibilityofanyturn-onorturn-offthumps
andothernoisesgeneratedbyanyupstreamequipment
fromcomingoutofthespeakers.
100 - 240V
50 - 60Hz 250W
POWER
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES FOR
THE U.S. AND ICES-003, FOR CANADA. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT
CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.
REVISION
SERIAL NUMBER
WARNING:
AVIS: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR
MOISTURE. DO NOT REMOVE COVER. NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS:
N'OUVREZ PAS LA COUVERTURE. N'EXPOSEZ
PAS CET ÉQUIPEMENT À LA PLUIE OU À L'HUMIDITÉ.
INPUTS FULL RANGEHIGH PASS
A
B
A
B
STEREO
MONO
NORMAL
INVERT
A
MEMDLYXVRVOL
BASS +2
TREBLE +2
AUX
LEVEL
2000W Digital Subwoofer
2000W
2W
3. Fan Vents
Donotobstructtheventilationopenings
ofthesubwoofer.Fansmoveairoverthe
heatsinkstocooldownthepowertransistors.
Iftheseventsarerestricted,thenthesubwoofermay
overheatandshutdown.
4. XLR Inputs
BalancedXLRfemaleconnectorsareprovidedforthe
leftandrightinputs.Connectthefull-rangeline-level
signalfromthemixer(orothersignalsource)tothese
inputjacks.
Ifyouareconnectingasinglesubwooferoutput,or
LFE(low-frequencyeffects)outputtothesubwoofer,
youmayuseeithertheAorBinputconnector.
NEVERconnecttheoutputofanamplier
directlytotheinputofthesubwoofer.
Thiscoulddamagetheinputcircuitryofthe
activesubwoofer.
