JBL 305PMKII [10/22] Section 4 305p 306p and 308p mkii powered studio monitors

Front View Back View

FEATURES

1. HIGH FREQUENCY TRANSDUCER (TWEETER) – This transducer reproduces high frequency signals.

2. WAVEGUIDE – The specially designed JBL Image Control Waveguide enhances imaging and optimizes

the blend of direct and reected sound in the room, ensuring neutral sound at the mix position.

3. POWER LED – This LED illuminates when power is connected and the POWER switch is set to ON. Note

that after turning the power switch to the ON setting, there is a short delay prior to illumination of the LED.

4. LOW FREQUENCY TRANSDUCER (WOOFER) – This transducer reproduces low frequencies.

5. DUST DOME – Protects the inner circuit of the woofer. This self-repairing dust dome is resistant to dents

caused by ngers and objects.

6. LOW FREQUENCY PORT – The patented Slip Stream™ Port works in conjunction with the low frequency

transducer to provide accurate low frequency performance.

7. INPUT PANEL – This panel includes the power connector, input connectors, and user controls.

8. PADS – Four self-adhering pads are supplied with each studio monitor.

Section 4: 305P, 306P, and 308P MkII Powered Studio Monitors
