JBL 305PMKII [7/22] Section 3 setting up your system

EACH 3 SERIES CARTON INCLUDES THE FOLLOWING ITEMS:

• One 3 Series MkII studio monitor or 3 Series subwoofer

• One power cord

• Quick setup guide

• Four peel-off rubber pads (305P, 306P, and 308P MkII models only)

UNPACKING

When removing a speaker from its packaging, we recommend the following procedure, which will prevent

damage of the high frequency transducer:

305P, 306P, and 308P MkII models:

1. Remove the outer shipping carton, if one exists.

2. Place the inner carton on the oor with the top facing upwards.

3. Open the top of the box.

4. Without removing the internal packaging end-cap, gently rotate the carton so the open end rests on the

oor and the bottom of the carton is facing you.

5. Gently lift the carton and allow the speaker and protective end-cap to slide out of the carton and remain

on the oor.

6. Save the cartons and use the above procedure in reverse when you want to repack the units for

shipment.

LSR310S subwoofer – The subwoofer weighs 19 kg (42 lbs). Unpacking the subwoofer does not require you to

lift the subwoofer. However, you will need to rotate the subwoofer in the carton. If you are unable to perform the

following steps without assistance, please request help from another person.

1. Remove the outer shipping carton, if one exists.

2. Place the carton on the oor with the bottom facing upward.

3. Open the bottom aps of the carton and remove any protective packing materials from the bottom of the

subwoofer. Open the bag that protects the subwoofer to expose the subwoofer’s four feet.

4. Gently rotate the carton so the bottom is facing the oor and the four feet of the subwoofer are in contact

with the oor.

5. Gently lift the carton and allow the subwoofer and protective packing materials to slide out and remain on

the oor.

6. Remove the protective packing materials and documentation from the top of the subwoofer. Save the

carton and use the above procedure in reverse when you want to repack the unit for shipment.

PLACEMENT

3 Series MkII Studio Monitors are designed to deliver exceptional imaging in any room. To get the most out of

your speakers, follow these recommendations:

• Locate the four self-adhesive rubber pads supplied with the 305P, 306P, and 308P MkII speakers. Position

and attach these to the bottom surface of the speaker close to each corner.

• Position each 305P, 306P, or 308P MkII Studio Monitor in a vertical orientation with the tweeter on top.

Vertical orientation eliminates phase shift and acoustic cancellation of frequencies that can occur when

the distance of the woofer to the ear is different from the distance of the tweeter to the ear.

• Angle the speakers so the high-frequency transducer in each speaker is aimed directly towards the ear

of the listener.

Section 3: Setting Up Your System
