Dsppa PC-1010P [4/5] Operation
![Dsppa PC-1010P [4/5] Operation](/views2/1989835/page4/bg4.png)
3
、
R
em
o
te
m
o
de
O
PERAT
ION
1. While press down any switch of CH1-CH10 on front panel with its indicator lit, the paging channel will
be switching on respectively. Press the switch again with the indicator getting off for resetting.
2.
“ADDRESS”on the rear panel should be used only for the remote mode .The PC1010P should be
set in order when there are many PC1010P being used. One PC1010R can control at most
16 PC1010P. 1-10 zones for the first PC1010P, 11-20 zones for the second PC1010P, it can reach
to 160 zones in total. The connection as below:
4
PC1010P
R
e
m
ote
P
a
g
i
n
g
P
C
1010
R
P
a
g
i
n
g
r
a
n
ge
up
to
2000
m
B
G
M
P
C
1015E
PC1013B/D
A
larm
I
n
A B
AMP. PC SERIES
