ALLEN & HEATH SQ-6 [4/4] Sq 6 introduction ap11349 issue 1
![ALLEN & HEATH SQ-6 [4/4] Sq 6 introduction ap11349 issue 1](/views2/1989974/page4/bg4.png)
Limited One Year Manufacturer’s Warranty
Allen & Heath warrants the Allen & Heath -branded hardware product and accessories contained in the original packaging ("Allen & Heath Product”) against
defects in materials and workmanship when used in accordance with Allen & Heath's user manuals, technical specifications and other Allen & Heath product
published guidelines for a period of ONE (1) YEAR from the date of original purchase by the end-user purchaser ("Warranty Period").
This warranty does not apply to any non-Allen & Heath branded hardware products or any software, even if packaged or sold with Allen & Heath hardware.
Please refer to the licensing agreement accompanying the software for details of your rights with respect to the use of software/firmware (“EULA”).
Details of the EULA, warranty policy and other useful information can be found on the Allen & Heath website: www.allen-heath.com/legal.
Repair or replacement under the terms of the warranty does not provide right to extension or renewal of the warranty period. Repair or direct replacement of
the product under the terms of this warranty may be fulfilled with functionally equivalent service exchange units.
This warranty is not transferable. This warranty will be the purchaser’s sole and exclusive remedy and neither Allen & Heath nor its approved service centres
shall be liable for any incidental or consequential damages or breach of any express or implied warranty of this product.
Conditions of Warranty
The equipment has not been subject to misuse either intended or accidental, neglect, or alteration other than as described in the User Guide or Service
Manual, or approved by Allen & Heath. The warranty does not cover fader wear and tear.
Any necessary adjustment, alteration or repair has been carried out by an authorised Allen & Heath distributor or agent. The defective unit is to be returned
carriage prepaid to the place of purchase, an authorised Allen & Heath distributor or agent with proof of purchase. Please discuss this with the distributor or
the agent before shipping. Units returned should be packed in the original carton to avoid transit damage.
DISCLAIMER: Allen & Heath shall not be liable for the loss of any saved/stored data in products that are either repaired or replaced.
Check with your Allen & Heath distributor or agent for any additional warranty information which may apply. If further assistance is required please contact
Allen & Heath Ltd.
Any changes or modifications to the equipment not approved by Allen & Heath could void the compliance of the product and therefore the user’s authority to
operate it.
SQ Series products comply with the European Electromagnetic Compatibility directive
2014/30/EU and the European Low Voltage directive 2014/35/EU.
Any changes or modifications to the product not approved by Allen & Heath could void the
compliance of the product and therefore the user’s authority to operate it.
SQ-6 Introduction | AP11349 Issue 1
Copyright © 2017 Allen & Heath. All rights reserved.
Allen & Heath Limited,
Kernick Industrial Estate, Penryn, Cornwall, TR10 9LU, UK
www.allen
-
heath.com
ALLEN&HEATH
Connections
Balanced mono/stereo inputs
Mic or line level
XLR
1=Gnd, 2=+, 3=
-
ST1 and
ST2
Inputs
Line level
¼”
TRS Jack
Tip= +, Ring=
-
, Sleeve=Gnd
ST3 Input
Line level
3.5mm Jack
Tip=Left
, Ring=
Right
, Sleeve=Gnd
Balanced XLR Outputs
Line level
XLR
1=Gnd, 2=
+, 3=
-
Balanced Jack Outputs
Line level
¼”
TRS Jack
Tip=
+, Ring=
-
, Sleeve=
Gnd
SLink
RJ45/E
therCON.
Use Cat5e or higher. Refer to individual expansion unit instructions.
AES Stereo Digital Output
Digital
XLR
Use 110
Ω
AES Cable
Rear USB Connection
USB
-
B, Conforms to USB 2.0 standard
Network Connection
RJ45, Use Cat5e or higher
Footswitch
¼”
TRS (dual) or TS (mono) Jack
Further Information and Support
There are many support resources available through our website including user guides, knowledgebase articles
and access to the Allen & Heath Digital Community.
For local language support, please contact the Allen & Heath distributor for your region.
