Avantis Getting Started Guide

6

AP11558 Issue 4

2. Connect and power up

2.1 Power Up

Ensure the rocker switch is in the off position. Plug in the IEC mains power lead supplied with the mixer. If

required, secure the lead by hooking it into the plastic clip using a T20 Torx to remove the fixing screw.

Power on the mixer using the rocker switch.

2.3 Recall a Template Show

Avantis has a fully configurable audio architecture, control layout, and socket patching. We have provided

a set of Template Shows to give a choice of classic console formats to load as a quick starting point with a

familiar architecture and logical layout.

To load a Template Show go to the Utility / Memory / Show Manager screen, select one of the available

Template Shows, touch Recall and confirm.

 Recalling a Show overwrites all the system settings including the bus configuration,

control layout, current parameters, all Scenes, and Library presets. If you want to

save the current settings then first Store them as a User Show.

 For more information please refer to the Avantis Firmware Reference Guide available

Switch on the Remote Expander. The SLink port Lnk/Err indicators flash at a steady rate when the link is

established. The red error indicator lights if a communication error is detected. Check that the cables are

the correct type, plugged in correctly, and are not faulty.

The following Remote Expanders are compatible with the Avantis SLink port:

Down button. Confirm the action and then turn the mixer and expanders off using their power switches.

 If the system is not powered down correctly there is a possibility recent changes

may be lost.

 If the system was not powered down as described above, then a “Not Shut Down

Correctly” screen appears the next time the system is turned on.
