Key Features:
• Ultimate news gathering microphone
• Extremely effective and unique handling-
noise isolation system
• Unsurpassed ruggedness and reliability in
every environment
• Self generating, no battery or phantom
power required
• Consistent response with distance, no
muddy lows when used close to lips
Technical Specifications:
:tnemelEnoitarene cG imanyD
:esnopseRycneuqer )F trahcees(zH000,31otzH08
:nrettaPralo lP anoitceridinmO
:Z-woL,ecnadepm sI mho051
tiucriCnepO,ytivitisneS
:zHk1,egatloV
lacsaP/Vm6.1
:lairetaMesa mC unimulA
:snoisnemi )D "57.7(mm791=htgneL
)"49.1(mm94=retemaiD.xaM
)"0.1(mm52=retemaiDknahS
:hsini kF calBssolG-imeS
:dedulcnIseirossecc )A kcalB(retpadAdnatS
:seirosseccAlanoitp nO eercsdniWlaocrahC673
neercsdniWkcalB1-973
neercsdniWdeR2-973
dnatSkseDA224
:thgieWte )N .zo5.9(smarg962
:thgieWgnippih )S .zo91(smarg935
RE50/B
Omnidirectional Dynamic
Microphone
General Description:
The Electro-Voice® RE50/B is specially shock-isolated,
omnidirectional, dynamic microphone created for the
most exacting professional applications. An advancement
in shock-mounting techniques, it was designed
particularly for handheld broadcast and sound-
reinforcement use. All handling noise, clothing noise, and
even cord shock have been isolated from the microphone
element so that mechanically induced noise is greatly
reduced. By use of a high-mass zinc internal acoustic
chamber, shock mounted within the machined-aluminum
outercasing, the RE50/B offers a degree of isolation
unprecedented in omnidirectional dynamic microphones.
The internal transducer uses a mechanical nesting
concept all its own. Each part is nested inside another so
that the transducer (head assembly) is nearly a solid
structure. It is highly resistant to damage from shock.
The diaphragm is unaffected by temperature extremes
and atmospheric conditions. A carefully designed integral
windscreen and blast filter provides excellent protection
from wind noise, excessive sibilance and annoying “P-
popping.” The RE50/B has a grille that bounces back to
retain its shape. A four-stage pop filter prevents dust and
magnetic particles
from reaching
the diaphragm. The
RE50/B’s attractive, nonreflecting, semi-gloss black finish
is ideal for on-camera use.
