08_ DVS OWNER MANUAL
TECHNICAL SPECIFICATIONS
DVS 4 DVS 6 DVS 8
PERFORMANCE
Frequency Response (-3dB)
(1)
75Hz - 20kHz 80Hz - 20kHz 75Hz - 20kHz
Frequency Range (-10dB)
(1)
60Hz - 30kHz 65Hz - 30kHz 60Hz - 30kHz
System Sensitivity (1W @1m)
(2)
84dB 88dB 90dB
Dispersion (-6dB) 110 degrees conical 90 degrees conical 80 degrees conical
Transducers Coaxial Coaxial Coaxial
Low Frequency 100mm (4.00”) mineral 165mm (6.5”) mineral 200mm (8.00”) mineral
loaded cone material loaded cone material loaded cone material
High Frequency 20mm (0.79) 20mm (0.79) 20mm (0.79)
Crossover 3.9kHz - 2nd order LF, 4.3kHz - 2nd order LF, 3.4kHz - 2nd order LF,
2nd order HF 2nd order HF 2nd order HF
Directivity (Q) 6.5 averaged 1kHz to 10kHz 10.6 averaged 1kHz to 10kHz 12.3 averaged 1kHz to 10kHz
Directivity (DI) 5.3 averaged 1kHz to 10kHz 9.6 averaged 1kHz to 10kHz 10.0 averaged 1kHz to 10kHz
Rated Maximum SPL
(2)
100dB (average) 105dB (average) 108dB (average)
106dB (peak) 111dB (peak) 114dB (peak)
Power Handling
Average 40W 60W 70W
Programme 80W 120W 140W
Peak 160W 240W 280W
Recommended Amplier Power 80W @ 6 Ohms 120W @ 6 Ohms 140W @ 6 Ohms
Nominal Impedance 6 Ohms 6 Ohms 6 Ohms
Distortion 10% Full Power (4.9V) 2nd Harmonic 3rd Harmonic (6.0V) 2nd Harmonic 3rd Harmonic (6.48V) 2nd Harmonic 3rd Harmonic
250Hz 0.738% 0.772% 0.934% 0.316% 1.86% 0.12%
1kHz 0.145% 0.234% 0.292% 0.560% 1.17% 0.54%
10kHz 0.070% 0.070% 0.740% 0.050% 1.10% 0.04%
Distortion 10% Full Power (5.5V) 2nd Harmonic 3rd Harmonic (1.9V) 2nd Harmonic 3rd Harmonic (2.05V) 2nd Harmonic 3rd Harmonic
250Hz 0.320% 0.311% 0.225% 0.326% 1.86% 0.12%
1kHz 0.078% 0.174% 0.082% 0.363% 1.17% 0.54%
10kHz 0.087% 0.087% 0.147% 0.066% 1.10% 0.04%
CONSTRUCTION
Enclosure ABS ABS ABS
Grille Steel, plated and painted Steel, plated and painted Steel, plated and painted
Connectors Euroblock type removable Euroblock type removable Euroblock type removable
locking connector with locking connector with locking connector with
screw terminals with screw terminals with screw terminals with
“loop through” facility “loop through” facility “loop through” facility
Supplied Accessories Yoke Bracket Yoke Bracket Yoke Bracket
Dimensions 277.0 x 170.4 x 165.6mm 340.5 x 212.2 x 216.5mm 451.8 x 290.0 x 296.0mm
(H x W x D) (10.91” x 6.71” x 6.52”) (13.41” x 8.36” x 8.52”) (17.79” x 11.42” x 11.65”)
Net Weight 1.8kg (3.96lbs) 3.1kg (6.83lbs) 5.3kg (11.67lbs)
Shipped Weight 5.4kg (11.9lbs) 8.6kg (11.9lbs) 14.6kg (32.16lbs)
Packed quantity 2 2 2
