![Tascam CD-240 [48/52] Specifications](/views2/1990423/page48/bg30.png)
Specifications
Audio formats
CD
CD-DA
Sampling frequency .............................44.1 kHz
Quantization bit rate ...............................16-bit
CD-DATA
MP3
Sampling frequency ...16 kHz, 22.05 kHz, 24 kHz, 32 kHz,
44.1 kHz, 48 kHz
Bit rate .........................8 kbps–320 kbps or VBR
WAV
Sampling frequency ...8 kHz, 11.025 kHz, 12 kHz, 16 kHz,
22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz
Quantization bit rate ........................8-bit, 16-bit
NET and USB
PCM
MP3
Sampling frequency ...8 kHz, 11.025 kHz, 12 kHz, 16 kHz,
22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz
Bit rate .........................8 kbps–320 kbps or VBR
WMA
Sampling frequency .......... 8 kHz, 11.025 kHz, 16 kHz,
22.05 kHz, 32 kHz, 44.1 kHz, 48 kHz
Bit rate .........................5 kbps–320 kbps or VBR
WMA Lossless
Sampling frequency ...44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Quantization bit rate ......................16-bit, 24-bit
WAV
Sampling frequency ...8 kHz, 11.025 kHz, 12 kHz, 16 kHz,
22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz,
64 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Quantization bit rate .................8-bit, 16-bit, 24-bit
AAC
Sampling frequency ...8 kHz, 11.025 kHz, 12 kHz, 16 kHz,
22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz,
48 kHz, 64 kHz, 88.2 kHz, 96 kHz
Bit rate .........................8 kbps–320 kbps or VBR
FLAC
Sampling frequency .......... 8 kHz, 11.025 kHz, 16 kHz,
22.05 kHz, 32 kHz, 44.1 kHz, 48 kHz,
64 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Quantization bit rate .................8-bit, 16-bit, 24-bit
Ogg Vorbis
Sampling frequency .......... 8 kHz, 11.025 kHz, 16 kHz,
22.05 kHz, 32 kHz, 44.1 kHz, 48 kHz
Bit rate ........................48 kbps–500 kbps or VBR
Apple Lossless
Sampling frequency ...8 kHz, 11.025 kHz, 12 kHz, 16 kHz,
22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz,
48 kHz, 64 kHz, 88.2 kHz, 96 kHz
Quantization bit rate ......................16-bit, 24-bit
DSD
Sampling frequency ........... 2.8224 MHz, 5.6448 MHz
Input/output connectors
LAN .............................................100BASE-T
USB .........................Front: USB 2.0 For iPod/iPhone
(+5V/1A power supply)
Rear: USB1.1 (Type A)
(+5V/500mA power supply)
DIGITAL OUTPUT
COAXIAL
Connector ................................. RCA Pin Jack
Compatible Signal Format ..Compliant with IEC-60958-3
standard for consumer applications (S/PDIF)
OPTICAL
Connector .........................TOS (JEITA RC-5720C)
Compatible Signal Format ..Compliant with IEC-60958-3
standard for consumer applications (S/PDIF)
ANALOG OUTPUT (BALANCED)
Connector .......................................XLR3-32
Output Impedance ................................200 Ω
Reference Output Level ...............+4 dBV (1.23 Vrms)
Maximum Output Level .............+20 dBV (7.75 Vrms)*
Output level adjustment range
.
0 dB to −14 dB (in 1.0dB steps)
ANALOG OUTPUT (UNBALANCED)
Connector ...................................RCA pin jack
Output Impedance ................................200 Ω
Reference Output Level ..............–10 dBV (0.32 Vrms)
Maximum Output Level .................+6 dBV (2.0 Vrms)
Output level adjustment range
.
0 dB to −14 dB (in 1.0dB steps)
4848
