Tascam CD-240 [7/52] Before use
![Tascam CD-240 [7/52] Before use](/views2/1990423/page7/bg7.png)
Before use
What’s in the box
Check to be sure the box includes all the supplied accesso-
ries shown below. Please contact the store where you
purchased this unit if any of these accessories are missing
or have been damaged during transportation.
Main unit × 1
A rack-mounting screw kit × 1
Remote control (RC-1310) × 1
Batteries for remote control (AAA) × 2
Owner’s manual (this document) × 1
Precautions for use
o Do not install this unit in a location that could become
hot. This includes places that are exposed to direct sun-
light or near a radiator, heater, stove or other heating
equipment. Moreover, do not place it on top of an
amplifier or other equipment that generates heat.
Doing so could cause discoloration or deformation.
o Avoid locations that are extremely cold or exposed to
excessive humidity or dust.
o In order to enable good heat dissipation, leave at least 20
cm (8") between this unit and walls and other equip-
ment when installing it. If you put it in a rack, take
precautions to prevent overheating by leaving at least 5
cm (2“) open above the top of the unit and at least 10 cm
(4“) open behind the unit.
o Do not put cloth on top of the unit or place the unit on
top of bedding or thick carpet. Doing so could cause
the unit to overheat or damage it.
o Do not lift or move the unit during playback because
the disc rotates at high speed. Doing so could damage
the disc.
o Always remove any loaded disc before moving this unit
or packing it for installation in a different location, for
example. Moving the unit with a disc inside could cause
a malfunction.
o This unit consumes power when in standby mode.
o Supply voltage to the unit that matches the voltage
indicated on the rear panel. If you are in any doubt
regarding this matter, consult an electrician.
o Do not open the body of the unit as this might result in
damage to the circuitry or cause electric shock. If a for-
eign object should get into the unit, contact your dealer.
o When removing the power plug from an outlet, always
pull directly on the plug. Never pull on the cord itself.
o If a TV is turned on while the unit is on, static might
appear on the TV screen depending on the characteris-
tics of the TV broadcast signal. This is not a malfunction
of the unit nor of the TV. If this occurs, turn the unit off.
Product registration
Customers in the USA, please visit the TASCAM website
(http://tascam.com/) to register as a user online.
Using the TEAC Global Site
You can download updates for this unit from the TEAC
Global Site:
http://teac-global.com/
1) Open the TEAC Global Site.
2) In the TASCAM Downloads section, click the desired lan-
guage to open the Downloads website page for that
language.
NOTE
If the desired language does not appear, click Other
Languages.
3) Click the “Search by Model Name” section to open the
Downloads page for that product.
4) Select and download any updates that are needed.
Maintenance
Wipe dirt from the top cover and other panel surfaces
using a soft cloth that has been slightly dampened with a
diluted neutral cleanser.
Do not use chemically-treated wipes, thinner or similar
substances because they could damage the surface of the
unit.
V
For safety, disconnect the power cord from the
socket before cleaning.
77
ENGLISH
