Outdoor DMX LED PAR manual

Our outdoor DMX LED PAR offers many possibilities to achieve the effects which you want. It is

suitable for DJs, bands, nightclubs and other performers who wants LED stage light . Please read the manual

before operation.

A. SPECIFICATION:

1. Weight: 3.5kgs

2. Size: 184*184*170mm

3. Power input: AC110-240V/50-60HZ

4. Wattage: 60W

5. LEDS:12*tri-3W LEDs

6. Beam angle:30 degree

7. IP rate:IP65

8. LED display for easier operation.

9. Selectable built-in programs, Auto running, DMX mode, M/S mode.

10. DMX modes: 3channels, 4channels, 8channels

B.OPERATION:

After power on, Press “MODE”button to activate the main menu: Built-in programs mode, Auto

running mode, DMX mode, Slave mode.

“SETUP” is to set the relative specification for current mode.

“UP” is to add the value of current specification.

“DOWN” is to decrease the value of current specification.

Built-in programs-- running one of 10 built-in programs

Auto run—running built-in programs one after another in continuous loop.

DMX mode--controlled by DMX controller

Slave mode—the projectors in this mode will be synchronously run with the projectors in master mode.

1. built-in programs mode

--Press “mode” until it shows “Pr.xx”to enter into built-in programs mode.

Press “up”and “down”to select program from Pr.01～Pr.10。

--Press “setup”button to enter into the running speed menu“SP××”.

Press “up”and “down”button to set the speed value from SP01～SP100（FL）.

--Press “setup”button to enter into the strobe menu “FS××”。

Press “up” and “down” to set up strobe value from FS00～99.
