©American DJ® - www.americandj.com - Reex Pulse LED™ Instruction Manual Page 4©American DJ® - www.americandj.com - Reex Pulse LED™ Instruction Manual Page 3
Reflex Pulse LED™ Precautions
Safety Issues:
• To reduce the risk of electrical shock or re, do not expose this
unit rain or moisture
• Do not spill water or other liquids into or on to your unit
• Do not attempt to operate this unit if the power cord has been
frayed or broken
• Do not attempt to remove or break off the ground prong from the
electrical cord. This prong is used to reduce the risk of electrical
shock and re in case of an internal short
• This unit is intended for internal use only, use of this product out-
doors voids all warranties written or implied.
• Two Independent Moving Heads
• Compact High-Tech Case Design
• Built-In Hanging Yoke
• Internal Microphone
• Sound Active
• Extreme Long Lifetime LEDs (100,000 hr. rating)
• Voltage is User Selectable
Reflex Pulse LED™ Features
Reflex Pulse LED™ Warranty Registration
The Reflex Pulse LED™ carries a three year (1095 days) limited war-
ranty. Please fill out the enclosed warranty card to validate your pur-
chase. All returned service items whether under warranty or not, must
be freight pre-paid and accompany a return authorization (R.A.) num-
ber. The R.A. number must be clearly written on the outside of the
return package. A brief description of the problem as well as the R.A.
number must also be written down on a piece of paper included in
the shipping carton. If the unit is under warranty, you must provide a
copy of your proof of purchase invoice. You may obtain a R.A. num-
ber by contacting our customer support team on our toll free custom-
er support number. All packages returned to the service department
not displaying a R.A. number on the outside of the package will be
returned to the shipper.
Reflex Pulse LED™ Fuse Replacement
Locate and remove the unit’s power cord. Once the cord has been
removed located the fuse holder located inside the power socket.
Insert a flat-head screw driver into the power socket and gently pry
out the fuse holder. Remove the bad fuse and replace with a new one.
The fuse holder has a built-in socket for a spare fuse be sure not to
confuse the spare fuse with active fuse.
Reflex Pulse LED™ Operation
Please carefully read and understand the instructions in this manual
thoroughly before attempting to operate this unit. These instructions
contain important safety information regarding the use and mainte-
nance of this unit. Please keep this manual with the unit, for future
reference.
Reflex Pulse LED™ General Instructions
Introduction: The American DJ® Reex P
ulse LED™
is a dual output
LED moon-ower effect. This fixture is designed for mobile DJ’s, clubs,
bands, roller rinks and any arena that requires a compact, light weight,
easy to use unit.
Power Supply: Before plugging your unit in, be sure the source volt-
age in your area matches the required voltage for your American DJ®
Reex Pulse LED™ before attempting operation.
General Operation: This fixture is designed to operate as a stand
alone sound active unit, there is no need of a controller. It has been
tested and there is no assembly necessary. The Reflex Pulse LED™
is ready to be plugged in out of the box, there is no power switch.
When this fixture is plugged in, the units two LED panels will start
to project preset designs, and the mirrors will move to the sound of
an audio source via an internal microphone. The audio sensitivity is
preset at the factory for optimum performance and is not user adjust-
able. The middle panel is a strobe effect, that can be activated by the
Strobe On/Off switch located at the bottom of the unit. The strobe
effect is random, it is not sound active. After plugging the unit if there
is no output, check the fuse. If the fuse has not popped, please con-
tact customer support for further instructions. This fixture features a
light weight case design and an adjustable hanging bracket.
