M-Audio Keystation Mini 32 - New [14/80] Troubleshooting

Troubleshooting

Troubleshooting MIDI Functionality

Keystation Mini 32 has been designed to make working with MIDI on your computer as simple as possible.

However, you may experience some difficulties. In many cases, the keyboard is not at fault, as the problem

lies with the receiving device or software. To counter this, the Panic and Full Reset functions are available to

assist you.

Panic Button (All Notes Off + Reset All Controllers)

If there are notes that will not stop playing, or if you find there is an effect on a voice that you do not want,

you can send a Reset All Controllers MIDI message.

To send a Reset All Controllers message:

1. Press the Edit button to enter Edit Mode and the Edit button will illuminate to full brightness.

2. Press the “PANIC.” key (D, 2nd white key from the left):

• An “All Notes off” MIDI message is sent.

• MIDI Controller 121, Value 0 and MIDI Controller 123, Value 0 is sent out on ALL MIDI Channels 1 - 16

• Edit Mode will disengage as soon as the Panic button is pressed, the Edit light will go to half brightness

indicating that programming is complete.

Full Reset

To send a Full Reset message:

1. Make sure your computer is running.

2. Switch on the Keystation Mini 32 by plugging in the USB Cable from your computer while simultaneously

holding down the Oct/Data “+” and “-” buttons.

This will reset all Data=_____ and controller assignments to the following values:

Parameter Factory Default

Program Number 000

Bank MSB Number 000

Bank LSB Number 000

Channel Number 00 (channel 1)

Octave shift 000

Transpose shift 000

Modulation Button MIDI CC 001

Volume Knob MIDI CC 007

Pitch Bend Buttons Pitch Bend

Octave Buttons - Assignment Data = Octave

Velocity 1 = Normal
