CHANGING THE BULB
Attention:Disconnect the
machine from the power supply
by removing the plug from the
main socket!
Replace bulb with same type rated 10 watts
(110-120V) or 15 watts (220-240V).
- Loosen screw (A) as illustrated. (1)
- Remove the cover (B).
- Unscrew the bulb and ¿ t new one (C).
(2)
- Replace the cover and tighten screw.
Should there be any problem, ask your local
dealer for advice.
