Liebherr GNP 2756 Premium NoFrost [7/12] Control
![Liebherr GNP 2756 Premium NoFrost [7/12] Control](/views2/1996871/page7/bg7.png)
-
polythene bags and sheets
-
polypropylene straps
-
nailed wooden frame with polyethylene panel*
u
Take the packaging material to an official collecting point.
4.6 Connecting the appliance
NOTICE
Risk of damage to the electronic control system!
u
Do not use stand-alone inverters (conversion of d.c. to a.c./
three-phase) or energy saving plugs.
WARNING
Fire and overheating hazard!
u
Do not use extension cables or multiple socket outlets.
The type of current (alternating current) and voltage at the
installation site have to conform with the data on the type plate
(see Appliance at a glance).
Connect the appliance only with a properly installed
socket outlet with earthing contact. The socket outlet
must be fused with 10 A or higher.
It must be easily accessible so that the appliance can
be quickly disconnected from the supply in an emer-
gency.
u
Check the electrical connection.
u
Plug in the power plug.
4.7 Switching on the appliance
Put the appliance into operation about 2 hours before first
loading food to be frozen.
Do not load food to be frozen before the temperature display
reads -18 °C.
u
Press On/Off button
Fig. 3 (7)
.
w
The temperature display and the alarm symbol flash until the
temperature is sufficiently low. If the temperature is above
0 °C, dashes flash. If it is below, the current temperature
flashes.
w
The interior light is on when the door is open.
5 Control
5.1 Brightness of the temperature
display
You can adjust the brightness of the temperature display to the
light conditions of the room in which the appliance is installed.
5.1.1 Adjusting the brightness
The brightness is adjustable between h0 (no illumination) and
h5 (maximum luminosity).
u
To activate the setting mode: press the SuperFrost button
Fig. 3 (8)
for about 5 s.
w
The display indicates c.
w
The menu symbol
Fig. 3 (3)
shines.
u
Using the Up setting button
Fig. 3 (1)
or Down setting
button,
Fig. 3 (2)
, select h.
u
To confirm: briefly press the SuperFrost button
Fig. 3 (8)
.
u
To make the display brighter: press Up button
Fig. 3 (1)
.
u
To make the display darker: press Down button
Fig. 3 (2)
.
u
To confirm: press SuperFrost button
Fig. 3 (8)
.
w
The brightness is adjusted to the new value.
u
To deactivate the set-up mode: press On/Off button
Fig. 3 (7)
.
-or-
u
Wait for 5 minutes.
w
The temperature is indicated again in the temperature
display.
5.2 Child proofing
The child-proofing function enables you to make sure that the
appliance is not inadvertently switched off by playing children.
5.2.1 Setting the child lock function
u
To activate the setting mode: press SuperFrost button
Fig. 3 (8)
for about 5 s.
w
The display indicates c.
w
The menu symbol
Fig. 3 (3)
shines.
u
Briefly press the SuperFrost button
Fig. 3 (8)
.to confirm.
When c1 is indicated in the display:
u
Tto activate the child lock, briefly press the
SuperFrost button
Fig. 3 (8)
.
w
The child lock symbol
Fig. 3 (11)
shines. c flashes in the
display.
When c0 is indicated in the display:
u
to deactivate the child lock, briefly press the SuperFrost
button
Fig. 3 (8)
.
w
The child lock symbol
Fig. 3 (11)
goes out. c flashes in the
display.
u
To deactivate the set-up mode: press On/Off button
Fig. 3 (7)
.
-or-
u
Wait for 5 minutes.
w
The temperature is indicated again in the temperature
display.
5.3 Door alarm
If the door is open longer then 60 s, the audible alarm sounds.
The audible alarm is automatically silenced when the door is
closed.
5.3.1 Muting the door alarm
The audible alarm can be muted when the door is open. The
sound switch-off function is active as long as the door is left
open.
u
Press alarm button
Fig. 3 (9)
.
w
The door alarm is silenced.
5.4 Temperature alarm
The audible alarm sounds if the freezer temperature is not cold
enough.
The temperature display and the alarm symbol
Fig. 3 (4)
flash
at the same time.
The cause of the temperature being too high may be:
-
warm fresh food was placed inside
-
too much warm ambient air flowed in when rearranging and
removing food
-
power failure for some time
-
the appliance is faulty
The audible alarm is automatically silenced, the alarm symbol
Fig. 3 (4)
goes out and the temperature display stops flashing
when the temperature is sufficiently cold again.
If the alarm status persists: (see Malfunction).
Note
Food may be spoilt if the temperature is not cold enough.
u
Check the quality of the food. Do not consume spoiled food.
Control
7
