40
EN
Special Functions
Cooking Fish
Use this function cook the fish types described in the table below.
1. Press the “On/Off” key to switch the oven on.
2. Press the “Cooking Fish” key. The function key
lights up.
3. Press the “–” and “+” keys to set the temperature.
4. Press the “>” button to insert the time definitions.
5. Press the “–” and “+” keys if you want to set the
desired Operating Time. This setting is optional.
Please jump to point 7 if you don’t want to set
duration.
6. If you want to modify any of the above parameters,
press the “<” or “>” keys to select the parameter and
then the “–” and “+” keys to set a different value.
7. Press the Start key. The oven will start to operate.
Programme
Type of Fish
Temperature ºC
Time (min)
B 01
Trout
80°C
25
B 02
Shrimp
90°C
15
B 03
Fish filet
80°C
18
B 04
Mussels
100°C
25
B 05
Lobster
100°C
30
