6
MAKING TOMATO JUICE
- Place the plastic screw locking ring
into the sleeve (fig. 1).
- Place the gauze into the sleeve next to
the plastic screw locking ring (fig. 2).
3.
Put the fixing ring through the sleeve
and make it at the end of the sleeve
(fig. 3).
- Place the snake into the head, long
end first, and turn to feed the snake
slightly until it is set into the motor
housing (fig. 4).
- Insert the shaft of the snake into the
central axis of the screw (fig.5).
- Put the whole sleeve along with the
fixing ring through the screw, then
move the fixing ring clockwise so that it
being fastened tightly (fig. 6).
- Put the plastic juice tray through the
sleeve and make it on the suitable
position (fig. 7).
- Insert the plastic screw into the hole
of the sleeve, then move it clockwise
until it is properly fastened. Then place
the plastic cover onto the sleeve (fig. 8)
- Now the appliance is ready for juicing.
CLEANING AND MAINTENACE
DISASSEMBLING
- Make sure that the motor has stopped
completely.
- Disconnect the plug from the power
outlet.
- Disassemble by reversing the steps
from 1-6 pictures.
- To remove the cutting plate easily,
place a screwdriver between the cutting
plate and the head as illustrated and lift
it up.
- Press the fasten knob, move the head,
then you can take out the head.
CLEANING
- Remove meat, etc. Wash each part in
warm soapy water.
- A bleaching solution containing
chlorine will discolor aluminum surfaces.
- Do not immerse the motor housing in
water, but only wipe it with a damp
cloth.
- Thinners and petrol will crack or
change the color of the unit.
- Wipe all the cutting parts by vegetable
oil -wet cloth.
TECHNICAL DATA
• Maximum power 1400 W
• Voltage 220-240 V
• Frequency 50 Hz
• Current 2.5 А
SET
Meat Grinder 1
Cutting plate 3
Cross knife 1
Kebbe attachment 1
Sausage attachment 1
Tomato juicer 1
Tray 1
Pusher 1
Instruction manual 1
Warranty book 1
Package 1
Environment friendly disposal:
You can help protect
the environment!
Please remember to
respect the local
regulations: hand in
the non-working
electrical equipment to
an appropriate waste
disposal centre.
The manufacturer reserves the
right to change the specification
and design of goods.
7
