CHECKING THE RADIO SYSTEM

CAUTION!

Always keep all body parts, hair and dangling or loose items away from a spinning propeller, as these could

become entangled.

NOTICE!

Always power on the transmitter before powering on the ESC.

Always power o the ESC before powering o the transmitter. Never transport the boat with the battery

connected to the ESC.

1. Turn the transmitter throttle and rudder trim to the middle position.

2. Power on the transmitter.

3. Connect a fully charged battery to the ESC.

4. Ensure the rudder moves in the proper direction when the controller is moved left or right.

5. Pull the throttle to full, then return the throttle to neutral, ensuring the propeller turns counterclockwise. The

ESC auto-sensing voltage cuto will engage when the ESC detects a low battery charge. Release the throttle

and recharge the battery when necessary.

TESTING YOUR BOAT IN THE WATER

1. Carefully place the boat in the water.

2. Operate the boat at slow speeds near the shoreline. Avoid objects in the water at all times.

3. Once you are comfortable operating the boat at slow speeds, it is safe to operate the boat farther from the shore.

TIP!

If you are using too much steering trim on your transmitter to make the boat drive straight, return the trim to

neutral and mechanically center the rudder. To do this, loosen the ball link from the rudder horn, then turn the

ball link on the linkage threads until the rudder is properly centered.

4. Bring the boat back to shore when you notice the boat starting to lose speed.

5. Power o the ESC and disconnect the battery packs.

6. Allow the motor, ESC and battery packs to cool before charging the batteries or operating the boat again.

ANTENNA TUBE INSTALLATION

1. Carefully feed the end of the receiver antenna through the grommet inside the hull.

2. Pull the antenna wire out of the grommet towards the outside of the boat, then slide

the antenna through the antenna tube.

3. Insert the tube into the grommet, then t the cap onto the tube.

4. Apply clear tape to the antenna, grommet and hull in the boat to keep the antenna

from moving.
