0478 121 9920 C - EN
38
1 Folding down the handlebar:
Transport position (for cleaning, for
space-saving transport and for storage of
the machine):
● Press the detent lever (1) downwards
and hold.
● Fold the handlebar (2) down forwards,
ensuring that the electric cable is not
damaged.
Working position (to push machine):
● Fold the handlebar (2) up rearwards
and ensure that the handlebar is fully
engaged.
2 Height adjustment:
The height of the mono handlebar can be
adjusted to 2 levels:
● Press the detent lever (1) downwards
and hold.
● Move the handlebar (2) into the
required position.
● Release the detent lever (1) and ensure
that the handlebar is again fully
engaged.
8.2 Dual handlebar (ME 443)
Transport position (for cleaning, for
space-saving transport and for storage of
the machine):
● Open the quick-clamping devices (1) –
fold downwards – and fold the upper
handlebar (2) forwards, ensuring that
the electric cable is not damaged.
Working position (to push machine):
● Fold up the upper handlebar (2)
rearwards and hold with one hand.
● Close the quick-clamping devices (1) –
fold upwards.
8.3 Grass catcher box
Attaching:
● Open the discharge flap (1) and
hold it open.
● Attach the grass catcher box (2) to the
mountings (3) on the rear of machine by
means of the locating lugs.
● Close the discharge flap (1).
Detaching:
● Open the discharge flap (1) and hold it
open.
● Lift the grass catcher box (2) and
remove it rearwards.
● Close the discharge flap (1).
8.4 Central cutting height
adjustment
Six different cutting heights
between 25 mm and 75 mm can be set.
Level 1 = lowest cutting height
Level 6 = highest cutting height
Setting cutting height:
● Hold the handle (1), pull the lever (2)
upwards and hold.
● Set the required cutting height by
moving the machine upwards and
downwards. The current cutting height
can be read off at the cutting height
indicator (3) by means of the
marking (4).
● Release the detent lever (2) and allow it
to engage.
8.5 Level indicator
The upper part of the grass catcher
box features a level indicator (1).
The flow of air that is created by the rotary
movement of the mowing blade and is
responsible for filling the grass catcher box
raises the level indicator (2):
The grass catcher box is filled with
clippings.
Danger of electric shock!
The electric cable must always be
attached to the quick-release clamp
body and the handlebar console.
Danger of pinching!
Before actuating the detent
lever (1), hold the upper
handlebar (2) with one hand at its
highest point and lift (relieve load)
slightly.
After actuation of the detent lever,
the upper handlebar can fall to the
lowest position under its own
weight.
Never place your finger between
the handlebar and the handlebar
console (under the detent lever).
Danger of pinching!
The upper handlebar can be folded
down by releasing the quick release
caps. For this reason, always hold
the upper handlebar (2) with one
hand at its highest point when you
open the quick-release caps.
7
8
9
10
