iCSPDA2 Installation Instructions
2
DISCLAIMER
Milestone AV Technologies, and its affiliated corporations and
subsidiaries (collectively, "Milestone"), intend to make this
manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Milestone
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Milestone assumes
no responsibility for accuracy, completeness or sufficiency of
the information contained in this document.
Chief® is a registered trademark of Milestone AV Technologies.
All rights reserved.
IMPORTANT WARNINGS
AND CAUTIONS!
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all components are
properly assembled and installed using the instructions
provided.
WARNING: Failure to provide adequate structural strength
for this component can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this component is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
component.
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components attached to the iCSPDA2 does not exceed
40 lbs (18kg).
i
AVISOS Y PRECAUCIONES
IMPORTANTES!
AVISO: Un AVISO llama su atención sobre la posibilidad de
sufrir lesiones de gravedad o incluso mortales si no sigue las
instrucciones.
PRECAUCIÓN: Una nota de PRECAUCIÓN llama su
atención sobre la posibilidad de dañar o destruir
el equipo si no sigue las instrucciones.
AVISO: Si no lee, comprende perfectamente y sigue todas
las instrucciones, podría causar daños graves, daños
personales y materiales o anular la garantía de fábrica. El
instalador es el responsable de asegurarse de que todos los
componentes están correctamente montados e instalados
siguiendo las instrucciones indicadas.
AVISO: Si no se proporciona la resistencia estructural
adecuada para este componente, podrían provocarse graves
daños personales o materiales. El instalador es el
responsable de asegurarse de que la estructura a la que este
componente está sujeta puede soportar cinco veces el peso
combinado de todo el equipo. Refuerce la estructura según
sea necesario antes de instalar el componente.
AVISO: Si se excede el peso máximo, podrían causarse
graves daños personales o materiales. El instalador es
responsable de asegurarse de que el peso combinado de
todos los componentes montados en el iCSPDA2 no excede
40 kg (18 libras).
WICHTIGE WARN- und
VORSICHTSHINWEISE!
WARNUNG: Ein WARNHINWEIS macht auf mögliche
schwere oder tödliche Verletzungen aufmerksam, die bei
Nichtbefolgung der Anweisungen eintreten können.
VORSICHT: Ein VORSICHTSHINWEIS macht auf Schäden
oder mögliche Zerstörung des Geräts aufmerksam, die bei
Nichtbefolgung der Anweisungen eintreten können.
WARNUNG: Falls nicht alle Anweisungen gelesen und gut
verstanden werden, kann dies zu schweren
Körperverletzungen, Schaden an den Geräten führen und die
Werksgarantie nichtig machen! Der Monteur ist dafür
verantwortlich, dass alle Komponenten unter Einhaltung der
mitgelieferten Anweisungen korrekt zusammengebaut und
eingebaut werden.
