DDE WYZ22-3 [4/13] Description

HANDLEBAR & CONSOLE

PART NO. DESCRIPTION QTY.

8 XSZ56-01 Handle Grip 1

9 2203200 Drive Clutch Lever 1

10 GB5787-86 Hex Hd. Flange Bolt M6x60mm 1

11 2203002A Upper Handle 1

12 90000-22 Small Spacer 4

13 XSZ56-1-09 Knob Nut M8mm 4

16 2203100 Flywheel Brake Lever 1

17 GB820-85 Phillips Hd Screw M6x40mm 1

18 WORD18.6-05 Rope Guide 1

19 GB6182-86 Nylon Insert Lock Nut M6mm 3

20 GB97.1-85 Flat Washer 6mm 3

21 2215300 Throttle Control Assembly 1

22 2203300 Cable Unit 1

23 WORD18-09 Wire Tie 4

24 XSZ56-1-15 Bolt, Handle 2

25 2203001 Lower Handle 1

26 GB801-88 Square Neck Bolt M8Ч40mm 2

27 2203400 Shift Lever Assembly 1
