DDE WYZ22-3 [6/13] Assembly

DDE WYZ22-1 [6/13] Assembly
MOWER DECK
ASSEMBLY
REF
NO.
PART NO.
DESCRIPTION QTY.
15 XSZ56-1-17 Hair Pin 4
19
GB6182-86 Nylon Insert Lock Nut
M6mm
4
20
GB97.1-85 Flat Washer 6mm 2
30
2205000 Right Bracket 1
31
2200003 Torsion Spring, Right 1
32
GB6182-86 Nylon Insert Lock Nut
M8mm
9
33
GB801-88 Square Neck Bolt
M8Ч16mm
6
34 2200007A Height Adjustment
Rack
1
35 GB5787-86 Hex Hd. Flange Bolt
M6x16mm
2
36 2200021 Torsion Spring 1
37
2200016 Mulch Cover 1
38
2213000 Mounting Bracket,
Discharging Chute
1
39
2200019 Pivot Shaft 1
40 2208000B Mower Deck 1
41
2211000 Middle Baffle 1
42 GB5787-86 Hex Hd. Flange Bolt
M8x35mm
2
43 GB5787-86 Hex Hd. Flange Bolt
M8x65mm
1
44
2210000A Rear Baffle 1
REF
NO.
PART NO.
DESCRIPTION QTY.
45 GB5787-86 Hex Hd. Flange Bolt
M6x12mm
5
46 XSS46-15 Rear Guard 1
47 2200006 Rod, Rear Guard 1
48
2200002 Torsion Spring, Left 1
49
2204000 Left Bracket 1
50 2200004 Rear Cover 1
51 2200001 Rod, Rear Cover 1
52
4LZ2.16.4-04 Rubber Ring 1
53 XSZ56-2-21 Pulley Spacer 1
54 XSZ56-2-20 Woodruff Key 1
55 GB78-85 Socket Set Screw
M6x8mm
2
56 XSZ56-2-22 Pulley 1
57 MXV4-370 V-Belt 1
58 2200015 Mulching Plug 1
59 2200017
Side Discharge Chute
1
60 8036 Decal，Logo 1
61 8205 Decal，Model Plate 1
63 8007 Decal，Danger 1
64 8008 Decal，Caution 1
65 8006 Decal，Warning 1
66 8051 Decal，Warning 1
6
