Gigabyte B365 S1151 MATX B365M H [22/44] Adjacent cache line prefetch
![Gigabyte B365 S1151 MATX B365M H [22/44] Adjacent cache line prefetch](/views2/2002888/page22/bg16.png)
& Package C State Limit
(Note 1)
Allows you to specify the C-state limit for the processor. AutoletstheBIOSautomaticallycongurethissetting.
(Default:Auto)
& CPU Thermal Monitor
(Note 1)
Enables or disables Intel
®
Thermal Monitor function, a CPU overheating protection function. When enabled,
the CPU core frequency and voltage will be reduced when the CPU is overheated. Auto lets the BIOS
automaticallycongurethissetting.(Default:Auto)
& Ring to Core offset (Down Bin)
AllowsyoutodeterminewhethertodisabletheCPURingratioauto-downfunction.Auto lets the BIOS
automaticallycongurethissetting.(Default:Auto)
& CPU EIST Function
(Note 1)
Enables or disables Enhanced Intel
®
SpeedStepTechnology(EIST).DependingonCPUloading,Intel
®
EIST technology can dynamically and effectively lower the CPU voltage and core frequency to decrease
average power consumption and heat production. AutoletstheBIOSautomaticallycongurethissetting.
(Default:Auto)
& Race To Halt (RTH)
(Note 1)
/EnergyEfcientTurbo
(Note 1)
Enables or disables the CPU power saving related settings.
& Voltage Optimization
Allowsyoutodeterminewhethertoenablevoltageoptimizationtoreducepowerconsumption.(Default:
Auto)
& Hardware Prefetcher
Allows you to determine whether to enable hardware prefetcher to prefetch data and instructions from the
memoryintothecache.(Default:Auto)
& Adjacent Cache Line Prefetch
Allows you to determine whether to enable the adjacent cache line prefetch mechanism that lets the
processorretrievetherequestedcachelineaswellasthesubsequentcacheline.(Default:Auto)
& ExtremeMemoryProle(X.M.P.)
(Note 2)
AllowstheBIOStoreadtheSPDdataonXMPmemorymodule(s)toenhancememoryperformancewhen
enabled.
Disabled Disablesthisfunction.(Default)
Prole1 UsesProle1settings.
Prole2
(Note2)
UsesProle2settings.
& System Memory Multiplier
Allows you to set the system memory multiplier. AutosetsmemorymultiplieraccordingtomemorySPD
data.(Default:Auto)
& Memory Ref Clock
Allowsyoutomanuallyadjustthememoryreferenceclock.(Default:Auto)
& Memory Odd Ratio (100/133 or 200/266)
Allowsyoutomanuallyadjustthememoryreferenceclock.(Default:Auto)
& Memory Frequency (MHz)
Therstmemoryfrequencyvalueisthenormaloperatingfrequencyofthememorybeingused;thesecond
is the memory frequency that is automatically adjusted according to the System Memory Multiplier settings.
(Note1) ThisitemispresentonlywhenyouinstallaCPUthatsupportsthisfeature.Formoreinformationabout
Intel
®
CPUs' unique features, please visit Intel's website.
(Note2) ThisitemispresentonlywhenyouinstallaCPUandamemorymodulethatsupportthisfeature.
- 22 -
