Gigabyte B365 S1151 MATX B365M H [25/44] Fan control mode
![Gigabyte B365 S1151 MATX B365M H [25/44] Fan control mode](/views2/2002888/page25/bg19.png)
& Fan Control Use Temperature Input
Allows you to select the reference temperature for fan speed control.
& Temperature Interval
Allows you to select the temperature interval for fan speed change.
& Fan Control Mode
Auto Lets the BIOS automatically detect the type of fan installed and sets the optimal control
mode.(Default)
Voltage Voltage mode is recommended for a 3-pin fan.
PWM PWM mode is recommended for a 4-pin fan.
& Fan Stop
Enables or disables the fan stop function. You can set the temperature limit using the temperature curve.
Thefanstopsoperationwhenthetemperatureislowerthanthelimit.(Default:Disabled)
& Temperature
Displaysthecurrenttemperatureoftheselectedtargetarea.
& Fan Speed
Displayscurrentfanspeeds.
& Temperature Warning Control
Sets the warning threshold for temperature. When temperature exceeds the threshold, BIOS will emit
warningsound.Optionsare:Disabled(default),60
o
C/140
o
F, 70
o
C/158
o
F, 80
o
C/176
o
F, 90
o
C/194
o
F.
& Fan Fail Warning
Allows the system to emit warning sound if the fan is not connected or fails. Check the fan condition or
fanconnectionwhenthisoccurs.(Default:Disabled)
- 25 -
