9
4. Pour the sucient volume of fresh/ tap water into reservoir up to the MAX. line marking.
5. Close and lock the top lid. Return the reservoir back into the chamber and lock it.
Turn ON the unit by pressing the “Power” button on the stick handle. Select either the “Power” or “ECO” mode by pressing the speed button. The “Power” mode provides maximum suction power and
the “ECO” mode operates at a lower sound level.
NOTE:
1. The formation of foam inside the reservoir may occur during the cleaning process. Slight foam formation is normal and does not hamper the functioning of the machine.
2. Detergent, soap powder, bleaching liquids and the like MUST NOT be added to the reservoir.
STOP
•
Turn OFF the unit by pressing the “Power” button again.
•
During short pauses in vacuuming, the vacuum cleaner can be left standing by leaning it slightly forward
NOTE: Please make sure that the device is on at, non-slippery oor and completely still before letting go of the handle. Failing to do so may result in device and/or oor damage.
CAUTION!
Always turn o the vacuum cleaner when left standing because the brush bristles may
damage a oor or carpet if left running.
INDICATOR LIGHTS
Battery full- blue light on
Battery below 20%- blue light ashing
Battery low- red light ashing
WASTE DISPOSAL
•
Change the water when it becomes dirty and at least after every usage. Do not vacuum for extended period of time with one lling of water. Check the water quality during cleaning and if the
water becomes too discolored or dense with dust and lint, unlock the top cover of reservoir and empty the reservoir and rell with fresh/clean tap water.
•
Empty the reservoir immediately after every usage.
WARNING: This product is designed for household only. The supplier is not responsible for
the damage caused by improper use or misuse of the product.
USING THE HANDHELD UNIT (see Picture 7)
•
Press the handheld release button on the main body to release the handheld unit. (Picture 7, Fig.8)
•
Insert the handheld unit into the main body for assembly. Make sure you hear the “click” sound which conrm that it is locked into the main body. (Picture 7, Fig.9)
•
Turn on the handheld unit by pressing the “Power” button on the handle.
•
Turn o the handheld unit by pressing the “Power” button again.
•
Always turn OFF the power and disconnect the charger from the supply before starting any maintenance.
CAUTION: The handheld unit is also not allowed to vacuum water or liquid.
NOTE: It is recommended to empty the dust container after every use. Please follow the instructions in the Cleaning and maintenance section.
CLEANING AND MAINTENANCE
Always turn OFF the power and disconnect the charger from the supply before starting any maintenance.
HANDHELD UNIT AND MAIN BODY
•
Wipe o any dirt from the vacuum using a dry and soft cloth.
•
In case of stubborn dirt, clean using a soft and slightly damp cloth soaked in a water solution diluted with a little neutral detergent and then wipe clean with a dry cloth.
•
Do not use soap powder, detergent and solvents like thinner, benzene, and spray type cleaners.
•
Dry immediately.
•
Ensure that there is no water in the nozzle after cleaning the handheld unit.
Handheld unit (see Picture 8)
•
Press the container button, remove the container and remove the dirt / dust after each use. (Picture 8)
•
Empty the contents into a dust bin. (see Picture 9, Fig.10)
•
Slide of the outer lter from the inner and remove the inner lter by turning the housing in the counter clockwise direction. (Picture 9, Fig.11) As indicated below, wash outer lter with tap water
and shake o the lter. (Picture 9, Fig. 12)
•
Allow to dry both completely before reinserting into the handheld unit.
NOTE: The handheld nozzle, inner and outer lter must not be put into dishwasher. They can be hand-washed only.
RESERVOIR DISPOSAL (see Picture 10)
1. Press the chamber release button to eject the chamber.
2. Pull out the reservoir handle and remove. (Picture 10, Fig.13)
3. Unlock both top locks of the reservoir. (Picture 10, Fig.14)
4. Take o the reservoir cover. Empty the reservoir and wash thoroughly.
5. Pull out the tube head. Turn the inner tube in an counter clockwise direction to the unlock (look at the marks). (Picture 10, Fig.15)
6. Wash the cover, tube head, inner tube and active carbon lter with tap water, let it dry completely before reinserting back into the reservoir cover.
7. Close and lock the top lid. Put the reservoir back into the chamber and lock it (“click” sound).
Floor nozzle (see Picture 11)
•
To take the oor nozzle out, lay the vacuum cleaner at on the oor. Press and hold the oor nozzle release buttons at the same time as indicated below and pull out the oor nozzle. (Picture 11,
Fig.16)
•
Carry out the cleaning and maintenance if any waste or hair has gotten tangled in the brush.
