![Falmec Quasar 80 Vetro (800) stec [18/80] Electronic control panel quasar glass](/img/pdf.png)
Falmec Quasar 80 Vetro (800) stec [18/80] Electronic control panel quasar glass
![Falmec Quasar 80 Vetro (800) stec [18/80] Electronic control panel quasar glass](/views2/2005383/page18/bg12.png)
16
2. ELECTRONIC CONTROL PANEL (Quasar Glass)
Mode push-button
Function: it turns hood motor on and off.
The function “desired speed” enables to start the motor at the speed that was selected
before the hood was last turned off.
Push-button -
Press to reduce motor speed
Display
It indicates the current speed
Push-button +
Press to increase motor speed
Timer
This function allows the automatic turning off of the hood after running for 15 minutes at
the speed previously set (the display shows a flickering light).
Light pushbutton
• ON: light on
• OFF: light off
Note: In order to maintain the correct functionality of the hood we recommend you to clean,
periodically, the front part of the glass. To rinse and dry carefully use a soft cloth. Che-
mical and abrasive products are strictly forbidden.
3. ELECTRONIC CONTROL PANEL (Quasar Glass EVO) (fig. P)
1: Timer/Alarm filters
The steady RED light indicates that the fat filter alarm is activated (after 30 hours), to de-
activate this alarm and zero the meters, maintain the Key pressed for 3 seconds.
Flashing RED light indicates that the timer function is activated. This function can only be
activated if the motor is activated and running at any velocity when the Key is pressed
(either prolonged or not). This function will cause the automatic switch-off of the hood
after 15 minutes.
With the Timer function activated, the hood can be switched-off by the operator in any
case and the function will be deactivated.
The Timer function remains associated to a velocity. A change in the velocity, with the
Timer function activated, will deactivate it.
2: 1st Velocity
When the LED is switched-off, non-prolonged pressing of the key will switch-on the hood
at the 1
st
velocity and illuminate the respective LED. The function will switch-on when the
Key is released.
When the LED is switched-off and another velocity is activated, pressing the Key will
imply selection of the 1
st
velocity, switching-on of the respective LED and switching-off of
the LED associated with the velocity that was previously selected.
When the LED is on, pressing the Key will imply the switching-off the LED and MOTOR.
When the LED is switched-off, prolonged pressing (at least 3 seconds) of the Key will
cause activation of the recirculation function. During the recirculation function (with a
duration of 24 hours), the LED will flash. From the activation of this function, the hood will
remain switched-on for one hour at the 1
st
velocity, after which it will switch-off for 3 hours
and then reactivate for another hour. These cycles are repeated until the timeout.
With this function activated, the other functions cannot be selected. To remove this func-
tion, keep Key 2 pressed for at least 3 seconds.
3: 2nd Velocity
When the LED is switched-off and another velocity activated, pressing the Key (either
prolonged or not) will imply the selection of the 2
nd
velocity, switching-on of the respec-
