Do not use abrasive products.

All the above operations must be performed after having disconnected the appliance from the

mains power supply.

SAFETY WARNINGS

The electrical system features an earth connection in compliance with international safety

standards; furthermore, it is compliant with the European standard for electromagnetic com-

patibility.

Do not connect the appliance to flues (from boilers, fireplaces, etc.). Make sure the mains volt-

age corresponds to the values on the rating plate located inside the range hood. The minimum

safety distance between the cooktop and the range hood must be at least 65 cm.

Never cook on “open” flames under the range hood.

Check deep-fryers during use: superheated oil may be flammable.

- Ensure there is adequate ventilation of the room when the rangehood is used at the same

time as appliances burning gas or other fuels.

- Do not flambe under the rangehood

- The exhaust air must not be discharged into a flue which is used for exhausting fumes from

appliances burning gas or other fuels.

- Ensure that all regulations concerning the discharge of exhaust air have been fulfilled before

you use the appliance.

Before performing any cleaning or maintenance operations, disconnect the appliance by un-

plugging it or using the main switch. The manufacturer disclaims all liability for any damage

that may be directly or indirectly caused to people, things and animals due to the failure to

follow all the instructions provided in this booklet and above all the warnings relating to the

installation, operation and maintenance of the appliance.

WARRANTY

The new equipment is covered by warranty.

The warranty conditions are provided by the distributor.

The manufacturer is not liable for any inaccuracies in this booklet resulting from printing or

transcription errors. The manufacturer reserves the right to modify its products as it consid-

ers necessary or in the interests of the user, without compromising their essential safety and

operating characteristics.

MOUNTING INSTRUCTIONS, RANGE HOODS

Step 1

- Rest the support bar against the wall (A-Fig. O1) at a height from the cooktop determined by

the sum of the distance X+517,8 mm.

- Check the horizontal alignment with a spirit level and mark the 2 holes to be drilled at the

ends of the bar.

- Drill the holes, insert 2 x 8mm dia. screw anchors, and fasten the bar using the corresponding

screws.

Step 2

- Hook the range hood to the support bar (Fig. O2).

- Adjust the alignment of the range hood using the screws on the brack-ets (Fig. O2). The top

screw (B) adjust the distance from the wall, the bottom screw (C) adjust the height.
