Technical data for the OMRON C21 basic Compressor with the Nebulizer kit:

Particle Size: **MMAD2.5μm-4.5μm

MMAD = Mass Median Aerodynamic Diameter

Aerosol%<5μm: 63% ± 10%

Medication Tank Capacity: 10ml maximum

Appropriate Medication Quantities: 2ml minimum - 10ml maximum

Residual volume of medication: 0.5 - 1.0ml

Sound: *Noise level (at 1 m distance) less than 45 dB

Nebulization Rate: *0.20 - 0.50ml/min

Aerosol Output: ** 0.37ml (2ml, 1%NaF)

Aerosol Output Rate: ** 0.05ml/min (2ml, 1%NaF)

Maximum permissible pressure inside the air tube: 400kPa

Result of cascade impactor measurements for particle size**

100

0.11 10 100

Cumulative % particle mass of sodium fluoride under size

Particle Size Dp (µm)

Cumulative Undersize %

Mean

Individual

* Measured by OMRON HEALTHCARE Co., Ltd. Measured with saline at ambient

temperature of 23°C and humidity of 40%. It may vary with the type of medication.

** Independently measured by Prof. Dr. Hiroshi Takano, Therapeutic Systems Research

Center, Doshisha University, Kyoto, Japan, according to EN13544-1:2007+A1:2009.

Note:

Performance may vary with medication such as suspensions or high viscosity. See

medication supplier’s data sheet for further details.
