Kenwood TH-K4E [115/154] Optional accessories

101

OPTIONAL ACCESSORIES

KHS-21

Headset

HMC-3

Headset (with VOX/ PTT)

EMC-3

Clip Microphone with

Earphone

BT-14

Battery Case (6 AA/ LR6)

KSC-24

Rapid Charger

BC-21

Battery Charger
