Kenwood TH-K4E [27/154] Th k2e k4e

TH-K2E/ K4E

Tuning control

VOL control

LED

(TX:Red RX:Green)

Display (LCD)

DC IN jack

Keypad

MENU key

MONI/SQL key

LAMP key

Power Switch

PTT switch

Antenna connector

SP/MIC jack
