4 To remove the battery pack, lift the safety catch, then

press the release latch to unlock the battery pack.

Lift the battery pack away from the transceiver.

INSTALLING ALKALINE BATTERIES

1 To open the BT-14 battery case lid, insert your thumb

or finger into the hole on the top of the battery case,

then pull the cover up.
