Example 2

To enter 145.000 MHz:

Key in Display

[#] ––– –––

[1], [4], [5] 1 4 5. – – –

[#] 1 4 5. 0 0 0

Example 3 (Short cut)

To enter 145.000 MHz:

Key in Display

1 4 4. 6 2 5

[#] ––– –––

[5] 5 – –. – – –

[ ] 1 4 5. – – –

[#] 1 4 5. 0 0 0

Example 4

To change 144.650 MHz to 145.650 MHz:

Key in Display

1 4 4. 6 5 0

[#] ––– –––

[1], [4], [5] 1 4 5. – – –

[VFO] 1 4 5. 6 5 0
