Master Section Overview

Main and Zone outputs are available in stereo, along with a separate mono output. All these

outputs are balanced on XLR connectors. Booth monitors output is available in stereo or

switchable to mono and again these outputs are balanced on XLR connectors.

A recording output is provided on gold plated phono sockets.

There are 3 insert loops provided. 1 & 2 are selected via the X-fade assign buttons and feature

latching and punch selector buttons along with wet / dry mixing control and gain trims. Mono and

cue switches are fitted to both sections. There is also an illuminated loop swap button that allows

the connected effects processors to be swapped over to the other channel.

The third effects loop is connected to the main output chain. This is selected by an illuminated

push button.

All effects loop connectors are pairs of 3 pole jacks, each socket providing send and return

paths.

Visual metering is by 2 twin 12 segment led VU meters; one for cue signals and one for output

signals.

Comprehensive headphones monitoring is provided featuring a powerful stereo headphones

amplifier.

6.5mm and 3.5mm stereo jacks are provided.

A split cue switch and monitor balance control are fitted.

The Console Microphone channel is located above the phones section and features two band

equalisation, volume control, illuminated on-off switch and cue button.

Dimensions (Exc. Knobs & connectors):

Width 483mm (19") Height 312mm (12.25"-7RU) Depth 110mm (4.33")

Power Supply

The Mixer has a fully regulated internal power supply that is designed to operate on

220-240Vac or 110-120Vac. Selection is by an internal switch that is accessed by removing the

fader panel.

DAMAGE MAY RESULT IF THE UNIT IS CONNECTED TO THE WRONG

SUPPLY VOLTAGE.

Fuses

Mains fuse sizes are 800mA anti-surge for 220-240Vac and 1.5A anti-surge for 110-120Vac

operation.

It is important for safety reasons that the correct fuse sizes are always

used.
