OCV 6
OCV 6 // issue 1.03 // 18.07.11
Tannoy adopts a policy of continuous improvement and product specication is subject to change
Tannoy (Direct UK) T: 00 44 (0) 1236 420199 E: enquiries@tannoy.com
TCGI (ROW sales) T: 00 45 8742 7000 E: info@tcgroup-international.com
TCGA (Americas sales) T: 00 1 (519) 745 1158 E: info@tcgroup-americas.com
Tannoy Middle East T: 00 971 (04) 4401208 E: enquiries@tannoy.com
Product Description
Tannoy OCV Series pendant loudspeakers deliver the renowned acoustic performance
and exceptional value of Tannoy’s CVS Series in-ceiling products in an architecturally
sensitive, self-contained, lightweight cylindrical enclosure. Engineered specically for
applications where consistent and high quality audio coverage is required in high or
open-ceilinged spaces – such as transport terminus, shopping malls or large double or
triple height commercial oors – without compromising clarity, intelligibility and SPL.
The unique cylindrical form-factor has been conceived to meet the exacting demands
of the architectural sector, minimising the impact on spatial aesthetics and allowing the
systems designer to locate the loudspeakers discretely in a manner that won’t conict
with other suspended systems such as lighting xtures and ventilation.
The Tannoy OCV 6 is, by design, a full bandwidth open-ceiling speaker system. The
design comprises a 165mm (6.5”) mid bass driver with a coaxially mounted 20mm
(0.79”) high frequency section mounted in the cylindrical ABS enclosure with mild steel
powder coated grille. The mineral loaded polypropylene cone material and nitrile rubber
surround enhance durability and long-term reliability.
The OCV 6 is also equipped with a low insertion loss 60W line transformer easily
congurable to the following settings via top mounted rotary tapping switch:
70V systems: 60W / 30W / 15W / 7.5W / OFF & low Impedance operation
100V systems: 60W / 30W / 15W / OFF & low Impedance operation
The OCV Series is available in either Black or White as standard.
Features
Applications
• Coaxially mounted 165mm (6.5”) mineral loaded
woofer with rubber surround and 20mm (0.79”) soft
dome diffraction loaded tweeter.
• High power & high sensitivity with extended frequency
response and very low distortion
• Wide, controlled constant-directivity 90 degree
dispersion for optimum coverage – minimising the
number of devices required for a given space
• Lightweight self-contained enclosure
• Architecturally sensitive cylindrical form factor for
minimal spatial impact
• Quick and easy hanging system for minimal
contractor time
• Easily accessible tapping switch on top of enclosure
• IP64 Rated for water and dust
• Airports
• Train Stations
• Retail Malls
• Casinos
• Conference Rooms
• Fitness Centres
• Convention Centres
• Ballrooms
• Theme Parks
• Hotels
