OCV 6
OCV 6 // issue 1.03 // 18.07.11
Tannoy adopts a policy of continuous improvement and product specication is subject to change
Tannoy (Direct UK) T: 00 44 (0) 1236 420199 E: enquiries@tannoy.com
TCGI (ROW sales) T: 00 45 8742 7000 E: info@tcgroup-international.com
TCGA (Americas sales) T: 00 1 (519) 745 1158 E: info@tcgroup-americas.com
Tannoy Middle East T: 00 971 (04) 4401208 E: enquiries@tannoy.com
TECHNICAL SPECIFICATIONS
System OCV 6
Frequency Response (-3dB)
(1)
80Hz - 20kHz
Frequency Range (-10dB)
(1)
60Hz - 30kHz
System Sensitivity (1W @1m)
(2)
88dB
Dispersion (-6dB) 90 degrees conical
Transducers
Coaxial
Low Frequency 165mm (6.5”) mineral loaded
cone material
High Frequency 20mm (0.79”)
Crossover 5.4kHz - 2nd order LF,
2nd order HF
Directivity Factor (Q) 11.3 averaged 1kHz to 6.3kHz
Directivity Index (DI) 10.5dB averaged 1kHz to 6.3kHz
Rated Maximum SPL
(2)
105dB (average)
111dB (peak)
Power Handling
Average 60W
Programme 120W
Peak 240W
Recommended Amplier Power 120W @ 16 Ohms
Nominal Impedance 16 Ohms
Distortion
10% Full Power (9.8V) 2nd Harmonic 3rd Harmonic
250Hz 0.42% 0.14%
1kHz 0.11% 0.31%
10kHz 1.27% 0.16%
1% Full Power (3.1V) 2nd Harmonic 3rd Harmonic
250Hz 0.16% 0.16%
1kHz 0.05% 0.18%
10kHz 0.27% 0.27%
Notes
(1) Average over stated bandwidth. Measured at 1 metre on axis in an
anechoic chamber
(2) Unweighted pink noise input, measured at 1 metre in an anechoic chamber
(3) Low Z operation
A full range of measurements, performance data, and Ease™ Data can be
www.tannoy.com
Tannoy operates a policy of continuous research and development. The introduction
of new materials or manufacturing methods will always equal or exceed the
published specications, which Tannoy reserves the right to alter without prior
notice. Please verify the latest specications when dealing with critical applications.
Ordering Information
PART NUMBER MODEL NAME COLOUR PACKED QUANTITY
8001 6060 OCV 6 BLACK 1
8001 6061 OCV 6 WHITE 1
Construction
Enclosure ABS / Steel
Grille Steel, plated and powder
coat painted
Connectors Euroblock type removable locking
connector with screw terminals with
“loop through” facility
Transformer settting Rotary switch
Dimensions
Bezel diameter 260mm (10.23”)
Overall Length 423mm (16.66”)
Net Weight 5.9kg (12.96lbs)
Shipped weight 7.5kg (16.53lbs)
Transformer Taps
(rear rotary switch)
70V 60W / 30W / 15W / 7.5W / OFF
& Low Impedance operation
100V 60W / 30W / 15W / OFF
& Low Impedance operation
Packed quantity 1
