OCV 6
OCV 6 // issue 1.03 // 18.07.11
Tannoy adopts a policy of continuous improvement and product specication is subject to change
Tannoy (Direct UK) T: 00 44 (0) 1236 420199 E: enquiries@tannoy.com
TCGI (ROW sales) T: 00 45 8742 7000 E: info@tcgroup-international.com
TCGA (Americas sales) T: 00 1 (519) 745 1158 E: info@tcgroup-americas.com
Tannoy Middle East T: 00 971 (04) 4401208 E: enquiries@tannoy.com
The self-contained, suspended open-ceiling loudspeaker shall consist of a 165 mm (6.5”) mineral loaded mid bass driver with coaxially mounted
20 mm (0.79”) high frequency unit and passive frequency dividing network mounted in a vented, cylindrical enclosure with mild steel powder coated
grille. The cylindrical chassis shall be constructed of steel. A standard euroblock connector shall be integrated into the top plate of the enclosure
providing audio connection. Suspension of the device is achieved through a steel cable locator arch on the top plate of the enclosure, engineered to
take in excess of total weight of device. Steel wire and ‘Gripple’ locking wire connectors are supplied for suspending at desired height from approved
ceiling-mounted hang point.
Performance of the suspended open-ceiling speaker shall meet or exceed the following criteria: The system shall have a conical coverage pattern of
90 degrees (1 kHz to 6 kHz). Frequency response measured on axis shall be 60 Hz – 30 kHz (-10 dB) from rated sensitivity, measured in an IEC
bafe in an anechoic chamber) with no equalization. Sensitivity shall be 88 dB (1 W @ 1 m). Long term average power handling capacity as dened
in EIA-426B test shall be 60 W, recommended amplier (program) power 120 W. The nominal system impedance shall be 16 Ohms (in low
impedance setting).
The open-ceiling speaker system shall be equipped with an integrated 60 W high performance line transformer for use in 70.7 or 100 Volt distributed
audio systems with 60, 30, 15, 7.5* Watt and OFF taps available. An easily accessible rotary switch located on the top panel (adjacent to euroblock
connector) shall be available for selecting transformer and low impedance settings. A weather resistant rubber weather booth shall provide protection
for the euroblock connection and tapping switch.
The diameter of the enclosure shall not exceed 260 mm (10.23”), overall depth from the top of the enclosure to the bottom shall not exceed 423 mm
(16.66”). The total weight of the device shall not exceed 5.9 kg (12.96 lbs). The device shall be available in black or white nish as standard.
The self-contained, suspended open-ceiling loudspeaker system shall be the…..OCV 6.
*70 Volt only
Architectural specications
