Viewing and Setting Routing

Pressing the OUTPUT button repeatedly will cycle through the available output groups, the currently selected output

group being indicated by the corresponding LED. For each output group, the LEDs of the input column will indicate

which input group(s) are connected to that output group. To set or change the input group(s) connected to a given

output group:

• Use the OUTPUT button to select the required output.

• Press

and hold

the OUTPUT button.

• With the OUTPUT button held, each press of the INPUT button will step through each possible input group for

that output.

• Once the required routing has been selected, releasing the OUTPUT button will store and activate your selection.

Please note that the

INPUT

button works only in combination with the

OUTPUT

button.

Where capacity is available, two input groups may be assigned to one output group – the AES and analogue input

groups of an Alpha-Link MADI-SX or LIVE for example can both connect to the MADI output group. Where this is

possible it will be indicated by illuminating both input group LEDs whilst stepping through the different modes.

In cases where two input groups are connected to a single output group, the order in which input groups are

assigned is determined by the ‘Connection Mode’ described in the System Settings and Diagnostics section of

this guide. Channels will be routed in order, hence the ‘lower’ input group will be fully used before the routing

spills over to the ‘higher’ group. Where this split occurs will depend on the sample rate and channel count and

may result in some channels remaining unused or un-routed.
