5
Front Panel
The front panels of each model of Alpha-Link are all broadly similar, differing only to reflect the different I/O options
provided (the unit illustrated here being an Alpha-Link MADI-SX).
Power Switch
This is used to switch the Alpha-Link on or off.
The current front panel settings are stored in non-volatile memory when the unit is switched off, and recalled
the next time it is switched on. When the Alpha-Link is used in combination with an SSL (or Soundscape)
Mixpander card the SSL Mixer software controls all front panel settings and the settings defined in the software
will be restored as soon as the unit is powered up again (if still connected to the Mixpander card).
Power Switch
Routing Matrix
Control
Clock Source
Selection
Headphones
(except Alpha-Link LIVE)
Sample Rate
Selection
Signal Meters
